Icom IC-R9500 Service Manual page 88

[VR-E BOARD]
REF ORDER
NO. NO.
J1* 6510020091 52808-0871
S1 2250000410 TP90D96E20-30F-2178-1
[VR-F BOARD]
REF ORDER
NO. NO.
R3 7210002970 RV-314 (RK0972210 10KB/10KB)
J1* 6510020091 52808-0871
[SENSOR UNIT]
REF ORDER
NO. NO.
W1 8900015710 OPC-1604
MP1 8930065891 2844 CLICK PLATE-1
MP2 8930071030 2844 S-COVER
MP3 8930065880 2844 SENSOR PLATE
MP4 8930065850 2844 SENSOR SPACER
MP5 8010020000 2844 SENSOR CHASSIS
MP6 8930065860 2844 P125 PLATE
MP7 8930065870 2844 P50 PLATE
MP8 8930056390 2500 SHAFT
MP9 8850001930 2500 SPRING
MP10 8930056351 2500 PLATE-1
MP11 8950006460 STEEL BALL D=2.5
MP12 8810000101 Screw PH M2X4 ZK3
MP13 8810010191 Screw BiH M2X4 SUS SSBC
MP14 8810009141 Screw PH M2.6X6 ZK3
MP15 8810003361 Setscrew (C) 3X6 ZC3
MP16 8850001970 C-ring M5 (stuck 200)
MP17 8850001900 Insulation Flat washer (AE)
MP18 8850000730 Insulation Flat washer (C)
MP19 8810003850 0tap type 3 PH B0 1.4X2.5 NI
MP20 8930071040 2844 CLICK SPRING
MP21 8810000101 Screw PH M2X4 ZK3
[MAIN UNIT]
REF ORDER
NO. NO.
J1 6510007020 TMP-J01X-V6
J21* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J41* 6510019981 52808-1671
J61* 6510021721 30FLT-SM2-TB (LF) (SN)
J91* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J1101* 6510019971 52808-1071
J2401* 6510019971 52808-1071
J3201 6510007020 TMP-J01X-V6
J3251* 6510025960 AXN330C238P
J3252* 6510021721 30FLT-SM2-TB (LF) (SN)
[LOGIC UNIT]
REF ORDER
NO. NO.
J1* 6510022490 AXK5S30045P
J2* 6510019870 AXK5S40045P
J52* 6510023261 B6B-PH-SM4-TB (LF) (SN)
J102* 6510019981 52808-1671
J604* 6510019971 52808-1071
J801 6510003441 B08B-EH-S (LF) (SN)
J802 6510003461 B10B-EH-S (LF) (SN)
J803* 6510020251 B9B-PH-SM4-TB (LF) (SN)
J805* 6510020081 52808-2071
J806* 6510022471 40FLT-SM2-TB (LF) (SN)
J811* 6510021721 30FLT-SM2-TB (LF) (SN)
J812* 6510021721 30FLT-SM2-TB (LF) (SN)
J813* 6510024151 50FY-BMT-TB (LF) (SN)
J814* 6510019981 52808-1671
J815* 6510021721 30FLT-SM2-TB (LF) (SN)
J816* 6510024521 12FLT-SM2-TB (LF) (SN)
J817* 6510020081 52808-2071
J818* 6510019971 52808-1071
J819* 6510021721 30FLT-SM2-TB (LF) (SN)
J820* 6510019981 52808-1671
J821* 6510019981 52808-1671
J822* 6510020521 52808-1271
J851* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J852* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J853* 6510019981 52808-1671
J900* 6510021721 30FLT-SM2-TB (LF) (SN)
S51* 2260001890 SKQDPA
MP101 8510016490 2590 LOGIC B-PLATE
MP103 8930063300 AL SHEET (AK)
MP203 8510016500 2590 LOGIC A-PLATE
MP806 8930059122 THERMALLY SHEET (AJ)-2
*: Refer to SECTION 7 BOARD LAYOUTS.
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
*
A B0 BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[SCOPE/TV UNIT]
REF ORDER
QTY.
NO. NO.
1
J301* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J401* 6510020081 52808-2071
1
J1001 6510007020 TMP-J01X-V6
J1301 6510007020 TMP-J01X-V6
J1601* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J2001 6510007020 TMP-J01X-V6
J2301 6510007020 TMP-J01X-V6
QTY.
MP1001 8510014870 2577 RX-VCO CASE
1
MP1081 8930014140 earth spring (D)
MP1102 8510017880 2844 MIX A-CASE
1
MP1403 8510015880 2590 S2LO CASE
MP1404 8930017190 earth spring (F)
MP1702 8510012400 2177 D/A CASE
MP2202 8510017880 2844 MIX A-CASE
QTY.
[CONNECT-A UNIT]
1
REF ORDER
1
NO. NO.
1
1
J1 6510023671 TCS4480-0141577
1
J2 6510023720 LGY6501-0600C
1
J3 6510023120 CD6109SA1J0
1
J4* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1
J101 6450001941 KEY-15S-2A3A (LF) (SN)
1
J201 6510024040 TM11R-5M2-88-LP
1
J202* 6510020251 B9B-PH-SM4-TB (LF) (SN)
1
J301 6510025640 JFJ3004-010010
1
J401* 6510021721 30FLT-SM2-TB (LF) (SN)
4
J501* 6510025670 31-5620-050-719-871+
4
J502* 6510024151 50FY-BMT-TB (LF) (SN)
2
J602 6510024032 UBA-4R-D10T-4D (LF) (SN)
1
J603* 6510024521 12FLT-SM2-TB (LF) (SN)
1
1
EP3 0800009560 SDCFJ-128-388
1
4
MP1 8850001860 Flat washer M3 SUS 3X6X0.5
1
MP2 8850000420 S-washer M3 NI
2
MP3 8930071850 2844 A-C SPRING
[CONNECT-B UNIT]
REF ORDER
QTY.
NO. NO.
1
RL1 6330001790 ATX203
1
RL121 6330001721 ATN207-K1
1
RL401 6330001790 ATX203
1
1
J1 6510023720 LGY6501-0600C
1
J101 6510024940 HEC2305-016250
1
J111 6510023671 TCS4480-0141577
1
J181 6510023720 LGY6501-0600C
1
J201 6510023750 01K1971-10
1
J202 6510007020 TMP-J01X-V6
J301 6450001130 JPJ2042-01-110
J401 6510023720 LGY6501-0600C
J501 6510023720 LGY6501-0600C
J601 6450001130 JPJ2042-01-110
QTY.
J602* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J603* 6510022191 B3B-PH-SM4-TB (LF) (SN)
1 J701 6450001800 JPJ1044-01-010
1
J702 6510007020 TMP-J01X-V6
1
J801 6510023750 01K1971-10
1 J802 6510007020 TMP-J01X-V6
1
J901* 6510021721 30FLT-SM2-TB (LF) (SN)
1
J902* 6510022801 B10B-PH-SM4-TB (LF) (SN)
1
1
F101 5220000230 S-N5054 #01
1
F102 5220000230 S-N5054 #01
1 F103 5210000031 FGB 1A PBF
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6 - 5
