REPLACING BATTERY

To replace the battery in the DPP-250 thermal printer follow the steps below.
Steps
:
1. Turn over the DPP-250 and place on a flat
surface. Rotate the (2) locking levers as
shown in the figure on the right.
2. Lift the battery cover as showed in the
figure on the right.
3. Lift the battery as shown in the figure on
the right.
4. Detach the battery connector as shown in
the figure on the right. Reverse Steps 1-4
to install the new battery pack.
