LOADING PAPER

The DPP-250 uses a drop-and-load design making paper loading easy and
trouble free. To load paper, simply lift up the paper cover latch and drop in
the new roll as shown in the steps below.
1. Slide the paper cover latch to unlock the
paper cover as shown in the figure on the
right.
2. Lift the paper cover latch to open the
paper cover as son as shown in the figure
on the left.
3. Drop in the new roll or thermal media as
shown in the figure on the right.
Be sure to pull at least 12mm or more of
media above the top of the printer
before closing paper cover.
4. Close the paper cover until it snaps lock.
5. Slide paper cover to lock the cover in
place.
