Technical Data - Infinite Peripherals DPP-250 User Manual

TECHNICAL DATA

General Specifications
Printing Specs
Printing Method
Printing Speed
Print Width
Resolution
Dot pitch
Resident Fonts
Loadable Fonts
Logo Registration
Input Buffer
Resident Barcodes
Communications
Emulation
Thermal Paper
Electrical
Power Supply
Magnetic Stripe
Reader
Environm ent
Reliability
M echanical
Dimensions
Weight
* Specifications subject to change without notice.
Line thermal dot printing
60mms/s (480 dots/sec) at 8.5 V
48mm / 384 dots per line
203dpi (8x9 dots/mm)
Horizontal – 0.125 mm (8 dots/mm)
Vertical- 0.125 mm (8 dots/mm)
Font А: 12 х 24 dots (32 char. per line);
Font B: 9 х 16 dots (42 char. per line);
Font C: 12 х 24 dots (32 char. per line);
Font D: 9 х 16 dots (42 char. per line);
1 Black and White size: 384 x 248 dots
128 KB (131072 bytes)
1D -EAN13, EAN8, UPC-A, UPC-E, Codebar, Code39, Code128
2D – PDF417, QR Code
RS232 C – max. 115200 bps,
USB v 1.1, compatible with 2.0
Bluetooth® (Optional) – for iOS and Android platforms
ESC/POS Continuous paper Mode
58mm +0/-1mm X 45mm diameter, thickness 60 µm
Rechargeable Li-ion battery (7,4 V / 1100 mAh)
Battery capacity: Per Charge (~20,000 lines)
AC adapter – DC 9 V, 1 A
AC 100 – 240 V, 1,3 A, 50/60 Hz
Magnetic Stripe Reader - 3 track unencrypted head, ISO7811 (optional)
Operating temp. +0°C to +45°C @ 35 to 85 % RH
Storage temp. -20°C to +60°C @ 10 to 90% RH
Printing Head: 50km (printing rate 25% max)
6 (W) X 113 (D) Х 57 (H)
295 g (without paper)
350 g (with paper)
USER MANUAL | 4
