DIP SWITCH SETTINGS

The DPP-250 is designed to use different methods of communications. Care
must be taken to ensure that the DIP Switches are not changed from its
default factory configuration unless required.
Dip Switch Settings
The printer has two absolutely different operation modes. They are
determined by the state of switch Sw2:
Continuous Paper mode
•
Black Mark mode
•
These two modes detect paper present conditions differently. The black mark
searching mode is designed for proper alignment of the starting print position
on indexed media with printed information.
Switch
SW1
SW2
SW3
SW4
OFF
Enable B T
Continuous P aper m ode
None
Normal o peration m ode
ON
Disable B T
Black M ark m ode
Xon/Xoff p rotocol
Protocol m ode
