STEP 9A INSTALL OVERLAY PANELS

Install Door Panel:
from the door handle.
Retain the screws.
Custom Handles
If you are using custom handles, the handle must
be properly secured to the panel before sliding the panel
into the trim.
handle and hardware.
Discard the supplied handle.
Installation Instructions
Use Front Holes
to Secure Handle
Use Rear Holes
to Secure Trim
Right hand models shown. Use the same instructions
for left hand models.
Handle
Trim
Move
Forward
For 3/4"
Panel
Supplied handle shown
in the overlay panel position.
Replace the handle side trim by installing the original
screws in the REAR screw holes.
screw holes.
19
Door Trim
Door
