Installation Instructions
STEP 6 SECURE UNIT TO WALL
corners of the unit in the access compartment.
Look through the access compartment to make
sure the rods line up with the anti-tip bracket.
Remove the washers and hair pin cotter from the end
of the rod.
bracket tab. Once it is in the slot, rotate the "L" rod
at the front end of the rod should be in a vertical
position. Do this to both sides.
in the bracket.
A hair pin cotter will be put through this hole to secure
the rod. If this hole appears to be too far away for
a snug fit against the unit, add the washers one
at a time until the pin will fit tightly into the hole.
the underside of the rod. Push the pin up until it snaps
into position. Pliers may be used. NOTE:
cotter must be vertical when this step is completed
to ensure the "L" rod is engaged in the bracket.
If the rod moves, remove the hair pin cotter and
place another washer on the rod. Reinsert the pin.
