Monogram Built-in refrigerators Installation Instructions Manual page 12

STEP 4 INSTALL ANTI-TIP BRACKET
WARNING:
the possibility of tipping forward.
AVERTISSEMENT :
CONTRE LES BASCULEMENTS
de son basculement vers l'avant.
attached to the wall in 4 places.
Mark the center with a vertical line.
on the wall.
at this height.
points on the horizontal line.
on the horizontal line. Align the center notch
on the bracket with the center line on the wall.
Select 2 holes that match with the located studs.
Make sure the holes selected are on the center
of the studs. Mark the wall at these points.
If one of the studs is closer to the end of the bracket,
mark an additional hole towards the center
of the bracket.
marked for the toggles to be mounted (not the stud
markings).
where marked. You will use 2 toggles with the metal
studs.
Installation Instructions
ANTI-TIP PRECAUTIONS
PRECAUTIONS
Two Additional
Hole Locations at
Ends of Brackets
Line on Wall
12
Wall Bracket
Center
Line On Wall
Wall Studs
