90° Door Swing - Monogram Built-in refrigerators Installation Instructions Manual

Top View
90° DOOR SWING
(optional setting)
Scale 1:1
Design Guide
Refrigerator
or Freezer
Door
Case Trim
23-7/8"
From Rear of
Unit
1/4"
1/2"
3/4"
1"
6
Frameless Cabinets:
cabinets at the top and sides.
may require filler strips
to prevent interference
with cabinet door swing.
for filler strips.
Cabinet Front
1/4"
1/2"
3/4"
1"
1-1/4"
1-1/2"
3/4" Overlay
Panel
(Nominal Size)
1-1/4"
