Opening the Printer

You need to open the printer every time you load media or perform
maintenance procedures.
To open the printer
1. Place the fingers of your right hand between the two notches on the lower
2. Grasp the front of the media cover with your left hand and lift the front of
3. Lift the media cover away from the top of the printer.
C o d e 39
NugFont
edge of the media cover (the media cover release) and pull the bottom of
the media cover away from the base of the printer.
the media cover upward to release it from the top of the printer frame.
2
I n t e I n t e
r m e r m e
c c
3 2
4 0
Preparing the Printer for Connection
3
1
Media cover
release
(between the two
notches)
1
Media
cover
3240G.004
