3. Installation

3.3. Removing the Inverter

Loosen the locking screws on either side of the inverter.
Removal is performed in the reverse order of mounting. With a firm grip at the lower end of the
inverter, lift the inverter approximately 20 mm vertically. Pull the inverter slightly away from the
3
wall. Push upwards at an angle until the wall plate releases the inverter. Lift the inverter away
from the wall plate.

3.4. Opening and Closing the Inverter

Illustration 3.7: Loosen Front Screws
12
Remember to observe all ESD safety regulations. Any electrostatic charge must be
discharged by touching the grounded housing before handling any electronic com-
ponent.
Use a TX 30 screwdriver to loosen the two
front screws. Turn the screwdriver until the
screws pop up. Screws are secured with a
spring and cannot fall out.
L00410309-07_02
