ADJUSTING THE 3-AXIS GIMBAL*

The Gimbal mechanism yields maximum rotation and placement as shown below.
NO IR
NO IR IR IR
Rotation 360 o Panning 360 o
NO IR IR
Tilting 90 Tilting 75
o o
