ADJUSTING THE 3-AXIS GIMBAL*

The Gimbal mechanism yields maximum rotation and placement as show below.
NO IR
IR
NO IR
IR
Rotation 360
Panning 360
o
o
NO IR
IR
Tilting 90
o
Tilting 75
o
17
