Digital Watchdog Snapit DWC-V4382D Manual page 28

SETUP
MONITOR
MODE 1 is the default. If the displayed image is not good enough, try MODE 2.
MODE 1
MODE 2
LANGUAGE
The camera supports the following languages: ENGLISH, CANTONESE, MANDARIN, JAPANESE, GERMAN, FRENCH,
ITALIAN, RUSSIAN, SPANISH, AND DUTCH.
OSD COLOR
The following colors are available for the OSD menu: BLUE, GREEN, CYAN, RED, MAGENTA, YELLOW, PURPLE,
and GRAY.
FACTORY SET
If selected, the camera reverts back to factory default settings.
NOTE: FACTORY SET does not affect the LENS, DAY & NIGHT, CAMERA ID, and DPC SETTINGS.
EXIT JUMP
Save the current settings and exit the OSD menu.
SAVE & EXIT
Exit the OSD menu without saving the changes.
EXIT
28
COMMUNICATION
OFF
If ON is selected, you can define the following:
ON
*PROTOCOL: PELCO-D only.
*CAMERA ID: Provide an ID number for the camera (0~255).
*BAUDRATE: 9600bps is the default. There are four options:
2400bps, 4800bps, 9600bps, and 19200bps.
*
