FLUSH MOUNT INSTALLATION INSTRUCTIONS*
For a flush mount housing, detach the surface mount base,
which is also known as the junction box, from the flush
mount base.
Use the mounting template to mark the holes for the screws
1
and a larger hole for the top extruded component of the
flush mount base.
The three assembly screws (ST4X35) fixed to the flush
2
mount base should be used to mount the camera to the
surface of the wall or ceiling.
Secure the three (3) assembly
3
screws.
10
Adjust the camera's position
4
by using the 3-Axis Gimbal.
ST4X35
Tighten the three locking
5
screws in with the L-Wrench
to secure the dome cover
over the camera.
