ADJUSTING THE CAMERA LENS*

Follow the instructions provided below to make any lens adjustments.
IR
Loosen the zoom and focus handles by rotating them counter-clockwise.
1
Adjust the field of view by moving the handle RIGHT (TELE) to zoom in or LEFT (WIDE) to zoom out.
2
After the desired zoom position has been established, adjust the Focus the same way as described
3
above.
Once the desired adjustments have been made, tighten the handles back by turning them clockwise.
4
16
Focus
Zoom
ZOOM: TELE
-
FOCUS: FAR -
NO IR
WIDE
NEAR
