2. OPERATION

2.1. Control panel

START/STOP
A:
Program start and stop.
Wash program selection
ADVANCED USE mode.
MOD
B:
Begin program delay (option)
ACCEL
Modification of the program in progress
C:
ON/OFF Switch.
D:
LEDs indicating the phase of the program in progress.
E:
Display. Shows the function in progress.
Main reports that appear on the display:
REPORT
Pr-* Program selected. Machine ready to wash.
A-*
Water inlet
Water temperature in Centigrade or
C-** / F***
Fahrenheit degrees
rt-*
Rotation time left.
Et-*
Extract time left.
End End of program. Door released
door Washer with door open
Operation
MEANING
fig. 1
9
