5. MAINTENANCE

Before performing any work on the washing machine, disconnect and mechanically lock the
-
external switch, and close and mechanically lock the manual water inlet valves.
Check the temperature of the parts to be handled, to avoid the risk of burns.
-
The dispenser may contain residues of chemical products. When handling this component, avoid
-
direct contact with the skin and use eye protection.
The draining pump and valve may contain residual water. When handling these components,
-
avoid direct contact with the skin and use eye protection.
Remember to reassemble ALL of the panels and place them correctly after any maintenance work.
-
5.1 Operations described
•
Cleaning the washer (section 5.2)
•
Cleaning the door seal (section 5.3).
•
Cleaning the electro valve filters (section 5.4)
•
Cleaning the dispenser (section 5.5)
•
Cleaning the draining pump (models HS-6008/EH020 with pumped drain) (section 5.6)
5.2. Cleaning the washer
•
We recommend periodic cleaning of the outside of the washing machine. Use a damp cloth or sponge.
•
To remove traces of grease, use mild soap and rinse as required.
•
Never use abrasive products or tools that could scratch or damage the surface of the washing machine.
5.3. Cleaning the door seal
•
Use a damp cloth or sponge.
•
Be especially careful to remove traces of laundry products or pieces of fabric that could be caught
between the folds of the seal.
•
Never use abrasive products or tools that could cut or damage the seal.
5.4. Cleaning the electro valve filters
Tools required:
•
Disassembly of the fittings: Slip-joint plier or pipe wrench diam. 1-½ in. (35 mm).
•
Disassembly of the filter supports: wrench 1-
•
Disassembly of the filtres: pliers.
Steps to follow
•
Disconnect and mechanically lock the external switch. Close and mechanically lock the manual water
inlet valves.
•
Check the temperature of the hot water inlet hose, so as to avoid the risk of burns.
•
Disassemble the fittings that connect the hoses to the washing machine.
•
Disassemble the filter supports (according to model).
•
Remove the filters from their housings and clean the filters with pressurised water. Place them back into
their housings.
•
Assemble the supports to the electrovalves (according to model).
•
Assemble the hoses in their corresponding inputs. Tighten the fittings.
•
Connect the external switch, open the manual water input valves and check the water tightness of the
coupling.
Maintenance
3
/ in. (34 mm).
8
20
