Panasonic KX-TDA30 Installation Manual

Hybrid ip-pbx.
Hide thumbs

Advertisement

Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
KX-TDA30: PSMPR Software File Version 5.0000 or later

Installation Manual

Hybrid IP-PBX
KX-TDA30
Model No.
SD Logo is
a trademark.

Advertisement

Table of Contents

   Related Manuals for Panasonic KX-TDA30

   Summary of Contents for Panasonic KX-TDA30

  • Page 1: Installation Manual

    KX-TDA30 Model No. Thank you for purchasing a Panasonic Hybrid IP-PBX. Please read this manual carefully before using this product and save this manual for future use. SD Logo is KX-TDA30: PSMPR Software File Version 5.0000 or later a trademark.
  • Page 2: System Components

    System Components System Components System Components Table Category Model No. Description Main Unit KX-TDA30 Main Unit Trunk Cards KX-TDA3180 4-Port Analogue Trunk Card (LCOT4) KX-TDA3182 3-Port DID Card (DID3) KX-TDA3183 2-Port Analogue Trunk Card (LCOT2) KX-TDA3188 E-1 Trunk Card (E1)
  • Page 3 Additional AC Adaptor KX-A228 S/M-type Back-up Battery Cable KX-T30865 Doorphone KX-T7765 Equipment Compatibility Compatible Panasonic Proprietary Telephones The PBX supports the following telephones: • Digital proprietary telephones (e.g., KX-DT300 series) • Analogue proprietary telephones (e.g., KX-T7700 series) • IP proprietary telephones (e.g., KX-NT300 series) •...
  • Page 4: Safety Notices

    Note • Some optional service cards and features are not available for certain countries/areas. Consult your certified Panasonic dealer for detailed instructions. • In this manual, the suffix of each model number (e.g., KX-TDA30NE) is omitted unless necessary. Safety Notices Please observe the safety notices in this manual in order to avoid danger to users or other people, and prevent damage to property.
  • Page 5: Important Safety Instructions

    Important Safety Instructions Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • Do not use the product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool.
  • Page 6: Important Information

    Unplug this unit from the AC outlet if it emits smoke, an abnormal smell or makes unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped and contact an authorised Panasonic Factory Service Centre. •...
  • Page 7 Important Information • When driving the screws into the wall, be careful to avoid touching any metal laths, wire laths or metal plates in the wall. • When this product is no longer in use, make sure to detach it from the wall. •...
  • Page 8 Important Information care facilities if any regulations posted in the area instruct you not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF (radio frequency) energy. DECT 6.0 Cell Station Medical—consult the manufacturer of any personal medical devices, such as pacemakers, to determine if they are adequately shielded from external RF (radio frequency) energy.
  • Page 9 Contact your telephone company. If all SLTs operate properly, there may be a problem with your PBX. Do not reconnect the PBX to the trunks until it has been serviced by an authorised Panasonic Factory Service Centre Installation Manual...
  • Page 10 A replacement fuse cover can be purchased from your local Panasonic dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE AC OUTLET IN YOUR PREMISES, THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
  • Page 11 Precaution 999 and 112 can be dialled on the apparatus after accessing the Exchange line for the purpose of making outgoing calls to the BT emergency services. During dialling, this apparatus may tinkle the bells of other telephones using the same line. This is not a fault and we advise you not to call the Fault Repair Service.
  • Page 12 Precaution • Some parameters required for compliance with Telecom’s Telepermit requirements are dependent on the equipment (PBX) associated with this modem. In order to operate within the limits for compliance with Telecom’s Specifications, the associated PBX equipment shall be set to ensure that modem calls are answered between 3 and 30 seconds of receipt of ringing.
  • Page 13: Installation Manual

    Introduction Introduction This Installation Manual is designed to serve as an overall technical reference for the Panasonic Hybrid IP-PBX, KX-TDA30. It provides instructions for installing the hardware, and programming the PBX using the Maintenance Console. The Structure of this Manual...
  • Page 14: Table Of Contents

    Installing/Removing the Optional Service Cards ............46 2.2.8 Types of Connectors ......................56 2.2.9 Attaching a Ferrite Core ....................58 2.2.10 Wall Mounting (KX-TDA30) ....................59 2.2.11 Wall Mounting (AC Adaptor) ...................62 2.2.12 Surge Protector Installation ....................66 Information about the Trunk Cards ................69 2.3.1 LCOT4 Card (KX-TDA3180) ..................69...
  • Page 15 Table of Contents 2.5.6 ESVM2 Card (KX-TDA3194) ..................105 2.5.7 EXT-CID Card (KX-TDA3168) ..................106 2.5.8 MEC Card (KX-TDA3105) ....................107 2.5.9 RMT Card (KX-TDA3196) ....................108 Connection of Extensions ....................109 2.6.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) ......109 2.6.2 Parallel Connection of the Extensions ................111 2.6.3 Digital EXtra Device Port (Digital XDP) Connection .............114 2.6.4...
  • Page 16 Table of Contents 4 Troubleshooting ...................239 Troubleshooting ......................240 4.1.1 Installation ........................240 4.1.2 Connection ........................241 4.1.3 Operation ........................243 4.1.4 Using the Reset Button ....................245 4.1.5 Troubleshooting by Error Log ..................246 5 Appendix ....................249 Revision History ......................250 5.1.1 PSMPR Software File Version 1.1xxx ................250 5.1.2 PSMPR Software File Version 2.0xxx ................251 5.1.3...
  • Page 17: System Outline

    Section 1 System Outline This section provides general information on the PBX, including the system capacity and specifications. Installation Manual...
  • Page 18: System Highlights

    1.1.1 System Highlights 1.1 System Highlights 1.1.1 System Highlights Networking Features This PBX supports the following networking features: TIE Line Service A TIE line is a privately leased communication line between two or more PBXs, which provides cost effective communications between company members at different locations. Virtual Private Network (VPN) VPN is a service provided by the telephone company.
  • Page 19: Hospitality Features

    PS is the sub telephone. PC Phone/PC Console Features This PBX supports PC Phone and PC Console. These Panasonic CTI applications provide advanced features combining telephone and PC, such as the ability to display detailed caller information, including a photograph, on the screen of the PC when a call is received, or to dial a telephone number automatically just by selecting a name.
  • Page 20: Basic System Construction

    1.2.1 Main Unit 1.2 Basic System Construction 1.2.1 Main Unit The main unit is equipped with 4 Super Hybrid Ports. For system expansion, optional service cards can be installed, and an additional AC adaptor can also be connected. Construction of Main Unit Front Cover Main Board Cable Cover...
  • Page 21: System Connection Diagram

    1.2.2 System Connection Diagram 1.2.2 System Connection Diagram ITSP Network Trunk (Telephone Company Lines) (e.g., ADSL Analogue/E1/BRI Modem) Remote PC Private IP Network Router Batteries IP-PT IP Softphone CTI Server Printer Fax Machine DSS Console External Sensor/ Wireless Phone External Relay Device DSS Console ISDN Telephone Doorphone &...
  • Page 22 1.2.2 System Connection Diagram KX-DT346/ KX-DT343/ KX-T7636/ DLC8 Console LCOT4 KX-T7633 DPT (KX-TDA3172) (KX-TDA3180) DLC4 CID4 (KX-TDA3171) (KX-TDA3193) Voice Processing SLC8 System PT-interface CS LCOT2 KX-DT300/ KX-DT300/ (KX-TDA3174) (KX-TDA3183) KX-T7600 KX-T7600 Analogue SLC4 Trunk (KX-TDA3173) Telephone DID3 (KX-TDA3182) Company E1 Line E1 Line E1 Line Wireless Phone...
  • Page 23: Optional Equipment

    1.3.1 Optional Equipment 1.3 Optional Equipment 1.3.1 Optional Equipment Maximum Model No. Model Name Description Quantity KX-TDA3105 Memory Expansion Card Memory expansion card to increase sys- (MEC) tem data storage space, double the num- ber of DPTs (using Digital XDP connec- tion), and enable Broadcasting, display language selection for VM Menu, and Call Billing for Guest Room features.
  • Page 24 Card (SIP-DSP4) on the SIP-GW4 card. KX-TDA3470 4-Channel VoIP Exten- 4-channel VoIP extension card. Compliant sion Card (IP-EXT4) with Panasonic proprietary protocol, and ITU-T G.729A and G.711 CODEC meth- ods. KX-TDA3480 4-Channel VoIP Gateway 4-channel VoIP gateway card. This card...
  • Page 25: Specifications

    Switching Non-blocking AC Adaptor AC Input • Panasonic PSLP1244: 100 V AC to 240 V AC; 1.5 A; 50 Hz/60 • Panasonic PSLP1434: 110 V AC to 240 V AC; 1.35 A; 50 Hz/ 60 Hz DC Output 40 V; 1.38 A (55.2 W) DC Input •...
  • Page 26 1.4.1 General Description Extension Connection Cable 1-pair wire (T, R) 1-pair wire (D1, D2) or 2-pair wire (T, R, D1, D2) 2-pair wire (T, R, D1, D2) PT-interface CS 1-pair wire (D1, D2) PT-interface CS (High-density) 4-pair wire (D1, D2) DSS Console and Add-on Key Mod- 1-pair wire (D1, D2) 275 mm (W) ´...
  • Page 27: Characteristics

    1.4.2 Characteristics 1.4.2 Characteristics Terminal Equipment Loop Limit • PT: KX-DT300/KX-T7600 series DPT: 90 W; all other DPTs/APTs: 40 W • SLT: 600 W including set Doorphone: 20 W • • PT-interface CS: 65 W 15 000 W minimum Minimum Leakage Resistance Maximum Number of Extension In- for PT or SLT struments per Line...
  • Page 28: System Capacity

    1.4.3 System Capacity 1.4.3 System Capacity Maximum Number of Trunks The PBX supports the following number of trunks. Line Type Maximum Number (Channels) LCOT + BRI + DID VoIP (H.323) VoIP (SIP) Maximum Terminal Equipment The following number of items of terminal equipment can be supported by the PBX. Depending on the type and total number of items of equipment to be connected, the MEC card may be required.
  • Page 29 1.4.3 System Capacity Without Additional AC Adap- Terminal Equipment Type With Additional AC Adaptor Doorphone Door Opener/External Relay External Sensor This number includes all ports of SLC cards, regardless of whether an SLT is connected or not. A maximum of 4 ports (8 channels) of a single VPS can be connected to the PBX. Note Devices connected to the PBX that exceed the system capacity will not function.
  • Page 30 1.4.3 System Capacity MEC Card Calculation Calculate the MEC figure from the type and total number of items of equipment to be connected. If the MEC figure exceeds 28, you need to install an MEC card. Note that you also need to connect an additional AC adaptor in this case.
  • Page 31 1.4.3 System Capacity AC Adaptor Selection (Without BRI Extension Port) You must connect an additional AC adaptor in any of the following conditions: • A total of more than 4 APTs, DPTs (except KX-DT300 series/KX-T7600 series/KX-T7560/KX-T7565), and DSS consoles (except KX-DT300 series/KX-T7600 series) are connected. •...
  • Page 32 Supplied AC Adaptor and Additional AC Adaptor If the load figure exceeds 96, it cannot be supported by the KX-TDA30. In this case, use the KX-TDA100 with M-Type Power Supply Unit (PSU-M), or the KX-TDA200 with either PSU-M or L-Type Power Supply Unit (PSU-L).
  • Page 33: Installation

    Section 2 Installation This section describes the procedures to install the PBX. Detailed instructions for planning the installation site, installing the optional service cards, and cabling of peripheral equipment are provided. Further information on system expansion and peripheral equipment installation is included. Installation Manual...
  • Page 34: Before Installation

    2.1.1 Before Installation 2.1 Before Installation 2.1.1 Before Installation Please read the following notes concerning installation and connection before installing the PBX and terminal equipment. Be sure to comply with all applicable laws, regulations, and guidelines. Safety Installation Instructions When installing telephone wiring, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Never install telephone wiring during a lightning storm.
  • Page 35 2.1.1 Before Installation Unplug the system from its power source when wiring, and plug the system back in only after all wiring is completed. Mis-wiring may cause the PBX to operate improperly. Refer to "Section 2 Installation" when wiring the system.
  • Page 36: Installation Of The Pbx

    2.2.1 Unpacking 2.2 Installation of the PBX 2.2.1 Unpacking Unpack the box and check the items below: Main Unit AC Cord AC Adaptor Screws for Wall Mounting Washers for Wall Mounting Mini Plug (for pager and music source) SD Memory Card Main Strap Optional Card Label Sheet KX-TDA30BX is supplied with 2 types of AC cord.
  • Page 37: Names And Locations

    2.2.2 Names and Locations 2.2.2 Names and Locations Earth Terminal Battery Connector DC IN 2 DC IN 1 Power Switch SD Memory Card Slot Cover Reset Button System Initialise Switch MOH port Pager port Super Hybrid Ports RS-232C port USB port Installation Manual...
  • Page 38: Opening/closing The Covers

    2.2.3 Opening/Closing the Covers 2.2.3 Opening/Closing the Covers Opening the Covers Pull the slide button to the right and, holding it, slide the cable cover upwards. Then turn the cable cover slightly to remove it. Slide Button Cable Cover Remove the three screws. Screw Holding the protrusions on both sides of the front cover, swing the cover open.
  • Page 39 2.2.3 Opening/Closing the Covers Removing/Attaching the Front Cover If you prefer, you can remove the front cover. Removing the Front Cover Holding the front cover open at about a 45° angle, remove the front cover by pushing it in the direction of the arrow as shown below.
  • Page 40 2.2.3 Opening/Closing the Covers Attach the rear hooks on the cable cover to the main unit, then swing the cable cover closed so that the front hooks fit in place. Cable Cover Slide the cable cover down until it locks. Installation Manual...
  • Page 41: Installation Of The Sd Memory Card

    To prevent data leakage, render the SD Memory Card physically unusable before disposal. Notice • Use only the SD Memory Card included with the PBX, or a Panasonic optional upgrade SD Memory Card. • The SD Memory Card must be inserted in the SD Memory Card slot of the PBX before startup.
  • Page 42 2.2.4 Installation of the SD Memory Card Note If you need to remove the SD Memory Card: Installation Manual...
  • Page 43: Frame Earth Connection

    2.2.5 Frame Earth Connection 2.2.5 Frame Earth Connection Loosen the screw. Screw Insert an earthing wire (user-supplied). Tighten the screw. Connect the earthing wire to earth. Earthing wire To earth WARNING • Connect the frame of the PBX to earth. •...
  • Page 44: Backup Battery Connection

    2.2.6 Backup Battery Connection 2.2.6 Backup Battery Connection The backup batteries and Back-up Battery Cable provide a backup power supply to allow full use of the PBX in the event of a power failure. In case of power failure, the backup batteries automatically maintain the power to the PBX without interruption.
  • Page 45 2.2.6 Backup Battery Connection Connecting Backup Batteries Turn off the power switch of the PBX. Connect the Back-up Battery Cable to a set of 3 identical batteries. Battery Connector Back-up Battery Cable Fuse Power Switch Black Backup Batteries (VRLA 12 V DC x 3) Installation Manual...
  • Page 46: Installing/removing The Optional Service Cards

    2.2.7 Installing/Removing the Optional Service Cards 2.2.7 Installing/Removing the Optional Service Cards Slot Position Slots 10 and 11 accept only cards that do not have external ports. Therefore, these slots do not have removable cover plates. Slot 01 contains the pre-installed Super Hybrid Ports. No optional service card can be installed. Slot Restrictions The following table shows the slot restrictions.
  • Page 47 2.2.7 Installing/Removing the Optional Service Cards Card Slot Number Type MSG2 ü ü ü ü SVM2 ü ü ü ü ESVM2 ü ü ü ü Only one of either the DLC4 or SLC4 card can be installed. A maximum of two DLC8 cards, two SLC8 cards, or one of each card can be installed. Only one of either the DPH4 or DPH2 card can be installed.
  • Page 48 2.2.7 Installing/Removing the Optional Service Cards Position the card in the open slot, making sure that the tabs on the both sides of the card fit into place. Then, holding the card firmly in place, lower the rear end so that the hole of the card fits over the extension bolt.
  • Page 49 2.2.7 Installing/Removing the Optional Service Cards Stick an appropriate optional card label (included) to the left side of the corresponding card. Optional Card Label Connect a cable to an appropriate port of the card. For details about pin assignments, refer to the appropriate section in "2.3 Information about the Trunk Cards"...
  • Page 50 2.2.7 Installing/Removing the Optional Service Cards To detach the LED holder LED holder To attach the LED holder Installation Manual...
  • Page 51 2.2.7 Installing/Removing the Optional Service Cards When installing a card in Slot 11, tighten the card using the screw included with the card, instead of the extension bolt. Screw Installation Manual...
  • Page 52: Cable Handling

    2.2.7 Installing/Removing the Optional Service Cards Cable Handling Attach the strap included with the card to one of the connected cables. Strap Bind all the connected cables together using the strap. Repeat the procedure for other cards. Installation Manual...
  • Page 53 2.2.7 Installing/Removing the Optional Service Cards Attach the main strap (included with the PBX) to any of the 5 rails depending on your preference. Main Strap Installation Manual...
  • Page 54 2.2.7 Installing/Removing the Optional Service Cards Bind all the connected cables together using the main strap, and then close the cable cover. For how to close the cable cover, refer to "2.2.3 Opening/Closing the Covers". Cable Cover Main Strap Note •...
  • Page 55 2.2.7 Installing/Removing the Optional Service Cards Removing the Optional Service Cards Loosen and remove the extension bolt. Holding the protrusions of the card, pull the card in the direction of the arrows. CAUTION When removing the optional service cards, do not put pressure on any parts of the main board. Doing so may result in damage to the PBX.
  • Page 56: Types Of Connectors

    2.2.8 Types of Connectors 2.2.8 Types of Connectors Connector Type Pin Number Used for • DPH4 (KX-TDA3161NE) RJ45 • DPH2 (KX-TDA3162) • DLC4 (KX-TDA3171NE) • DLC8 (KX-TDA3172NE) • SLC4 (KX-TDA3173NE) • SLC8 (KX-TDA3174NE) • LCOT4 (KX-TDA3180NE) (Twisted pair cable) • LCOT2 (KX-TDA3183) •...
  • Page 57 Main Board (Pager port, MOH port) Mini Plug The KX-TDA30E, KX-TDA30NE, and KX-TDA30GR have the Super Hybrid Ports with RJ45 connectors. Other models of the KX-TDA30 (other than the KX-TDA30E, KX-TDA30NE, and KX-TDA30GR) have the Super Hybrid Ports with RJ11 connectors. Installation Manual...
  • Page 58: Attaching A Ferrite Core

    2.2.9 Attaching a Ferrite Core 2.2.9 Attaching a Ferrite Core A ferrite core must be attached when an RJ45 connector is connected to the SIP-GW4 or IP-EXT4 card. Attaching to an RJ45 Connector For SIP-GW4/IP-EXT4 Cards Wrap the cable once around the ferrite core, then close the case of the ferrite core. Attach the ferrite core 5 cm away from the connector.
  • Page 59: Wall Mounting (kx-tda30)

    2.2.10 Wall Mounting (KX-TDA30) 2.2.10 Wall Mounting (KX-TDA30) Mounting on Wooden Wall WARNING Only use the wall-mounting equipment (screws, washers) included with the PBX. CAUTION • Do not block the openings of the cabinet. Leave at least 20 cm of space above and 10 cm to the sides of the PBX for ventilation.
  • Page 60 2.2.10 Wall Mounting (KX-TDA30) Hook the main unit on the screw heads. Mounting on Concrete or Mortar Wall WARNING Only use the wall-mounting equipment (screws, washers) included with the PBX. CAUTION • Do not block the openings of the cabinet. Leave at least 20 cm of space above and 10 cm to the sides of the PBX for ventilation.
  • Page 61 2.2.10 Wall Mounting (KX-TDA30) Install three anchor plugs (user-supplied) in the wall. Anchor Plug Hammer 8 mm 30 mm Install the screws (included) in the wall. Drive the screw to this position. Hook the main unit on the screw heads.
  • Page 62: Wall Mounting (ac Adaptor)

    2.2.11 Wall Mounting (AC Adaptor) 2.2.11 Wall Mounting (AC Adaptor) Mounting on Wooden Wall WARNING Only use the wall-mounting equipment (screws, washers) included with the PBX. Notice Be careful not to drop the AC adaptor. Place the reference for wall mounting (on the following page) on the wall to mark the 2 screw positions. 110 mm Install the screws and washers (included) in the wall.
  • Page 63 2.2.11 Wall Mounting (AC Adaptor) Mounting on Concrete or Mortar Wall WARNING Only use the wall-mounting equipment (screws, washers) included with the PBX. Notice • When driving the screws into the wall, be careful to avoid touching any metal laths, wire laths or metal plates in the wall.
  • Page 64 2.2.11 Wall Mounting (AC Adaptor) Hook the AC adaptor on the screw heads. Installation Manual...
  • Page 65 2.2.11 Wall Mounting (AC Adaptor) Reference for Wall Mounting Please copy this page and use as a reference for wall mounting. Install a screw here. 110 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.
  • Page 66: Surge Protector Installation

    2.2.12 Surge Protector Installation 2.2.12 Surge Protector Installation Overview A massive electrical surge can be caused if lightning strikes a telephone cable 10 m above ground, or if a telephone line comes into contact with a power line. A surge protector is a device that is connected to a trunk to prevent potentially dangerous electrical surges from entering the building via the trunk and damaging the PBX and connected equipment.
  • Page 67 2.2.12 Surge Protector Installation Outside Installation (Main Building) Surge Protector Trunk (Another Building) Trunk Extn. Terminal Board Surge Extn. Protector Extn. Extn. Earth Extn.: Extension Line If you install an extension outside of the building, the following precautions are recommended: Install the extension wire underground.
  • Page 68 2.2.12 Surge Protector Installation Connect the earth rod to the surge protector using an earthing wire with a cross-sectional area of at least 1.3 mm Bury the earth rod near the protector. The earthing wire should be as short as possible. The earthing wire should run straight to the earth rod.
  • Page 69: Information About The Trunk Cards

    2.3.1 LCOT4 Card (KX-TDA3180) 2.3 Information about the Trunk Cards 2.3.1 LCOT4 Card (KX-TDA3180) Function 4-port analogue trunk card with 2 power failure transfer (PFT) ports. One CID4 card can be mounted on the LCOT4 card (refer to "2.3.3 CID4 Card (KX-TDA3193)"). PFT Port 2 PFT Port 1 RJ45...
  • Page 70 2.3.1 LCOT4 Card (KX-TDA3180) RJ11 Connector Signal Name Function Ring – Reserved Installation Manual...
  • Page 71: Lcot2 Card (kx-tda3183)

    2.3.2 LCOT2 Card (KX-TDA3183) 2.3.2 LCOT2 Card (KX-TDA3183) Function 2-port analogue trunk card with 2 power failure transfer (PFT) ports. PFT Port 2 PFT Port 1 RJ45 To trunk Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Strap ´ 1, Optional Card Label ´ 1 User-supplied (not included): RJ45 connector Note •...
  • Page 72: Cid4 Card (kx-tda3193)

    2.3.3 CID4 Card (KX-TDA3193) 2.3.3 CID4 Card (KX-TDA3193) Function 4-port Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF. To be mounted on the LCOT4 card. CID4 Card LCOT4 Card Accessories and User-supplied Items Accessories (included): none User-supplied (not included): none Note If you need to remove the CID4 Card:...
  • Page 73: Did3 Card (kx-tda3182)

    2.3.4 DID3 Card (KX-TDA3182) 2.3.4 DID3 Card (KX-TDA3182) Function 3-port DID analogue trunk card. RJ11 To trunk Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Strap ´ 1, Optional Card Label ´ 1 User-supplied (not included): RJ11 connector Note To confirm the trunk connection, refer to "Confirming the Trunk Connection"...
  • Page 74: E1 Card (kx-tda3188)

    2.3.5 E1 Card (KX-TDA3188) 2.3.5 E1 Card (KX-TDA3188) Function 30-channel E1 trunk card. ITU-T standard compliant. BNC (TX) BNC (RX) LEDs RJ45 To NT1/Extension To NT1/Extension Accessories and User-supplied Items Accessories (included): none User-supplied (not included): RJ45 or BNC connector Note •...
  • Page 75: Switch Settings

    2.3.5 E1 Card (KX-TDA3188) Switch Settings For RJ45 120Ω 75Ω For BNC 120Ω 75Ω For Frame Ground Open For Frame Ground Short BNC (RX) outer conductor BNC (TX) outer conductor Switch Type Usage and Status Definition Select 120 W (default) or 75 W to match the connector type to be used. Termination Slide Slide...
  • Page 76: Led Indications

    2.3.5 E1 Card (KX-TDA3188) RJ45 Connector for Extension Use Signal Name Level [V] Function Transmit data (-) Transmit data (+) Receive data (+) Receive data (-) – – Reserved BNC (coaxial) Connector (TX) Signal Name Level [V] Function Transmit data (+) 1 (TX+) 2 (TX-) Transmit data (-)
  • Page 77 2.3.5 E1 Card (KX-TDA3188) Maximum Cabling Distance of Extension Connection The maximum length of the extension cable that connects the E1 cards is shown below: Diameter Maximum Distance 0.5 mm: 200 m Installation Manual...
  • Page 78: Bri2 Card (kx-tda3280)

    2.3.6 BRI2 Card (KX-TDA3280) 2.3.6 BRI2 Card (KX-TDA3280) Function 2-port ISDN Basic Rate Interface card with 1 power failure transfer (PFT) port. EURO-ISDN/ETSI compliant. RJ45 (LINE 1) RJ45 (LINE 2) LED 1 (LINE 1) To NT1/Extension LED 2 (LINE 2) Accessories and User-supplied Items Accessories (included): Extension Bolt ´...
  • Page 79 2.3.6 BRI2 Card (KX-TDA3280) Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Transmit data 1 TX1(+) RX2(+) RX1(-) Receive data 2 TX2(-) Receive data 1 Transmit data 2 – – Reserved RJ45 Connector for Extension Use Signal Name Level [V] Function...
  • Page 80 2.3.6 BRI2 Card (KX-TDA3280) Master Layer 1 Layer 2 LED Pattern Clock Layer 1: ON (Synchronous) Layer 2: ON (Link established)/OFF (Link not established) Master Clock: ON (Master)/OFF (Slave) Maximum Cabling Distance of S0 Bus Connection The maximum length of the extension cable that connects the PBX and the ISDN terminal equipment (TE) is shown below: CAT 5: Under 1000 m Point-to-Point...
  • Page 81: Bri1 Card (kx-tda3283)

    2.3.7 BRI1 Card (KX-TDA3283) 2.3.7 BRI1 Card (KX-TDA3283) Function 1-port ISDN Basic Rate Interface card. EURO-ISDN/ETSI compliant. RJ45 To NT1/Extension Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Strap ´ 1, Optional Card Label ´ 1 User-supplied (not included): RJ45 connector Note •...
  • Page 82 2.3.7 BRI1 Card (KX-TDA3283) Pin Assignments RJ45 Connector for Trunk Use Signal Name Level [V] Function Transmit data 1 TX1(+) RX2(+) RX1(-) Receive data 2 TX2(-) Receive data 1 Transmit data 2 – – Reserved RJ45 Connector for Extension Use Signal Name Level [V] Function...
  • Page 83 2.3.7 BRI1 Card (KX-TDA3283) Master Layer 1 Layer 2 LED Pattern Clock Layer 1: ON (Synchronous) Layer 2: ON (Link established)/OFF (Link not established) Master Clock: ON (Master)/OFF (Slave) Maximum Cabling Distance of S0 Bus Connection The maximum length of the extension cable that connects the PBX and the ISDN terminal equipment (TE) is shown below: CAT 5: Under 1000 m Point-to-Point...
  • Page 84: Ip-gw4 Card (kx-tda3480)

    2.3.8 IP-GW4 Card (KX-TDA3480) 2.3.8 IP-GW4 Card (KX-TDA3480) Function 4-channel VoIP gateway card. This card also enables CTI communication and system programming via a LAN. Compliant with VoIP H.323 V.2 protocol, and ITU-T G.729A, G.723.1, and G.711 CODEC methods. CSTA Phase 3 protocol compatible.
  • Page 85 2.3.8 IP-GW4 Card (KX-TDA3480) Pin Assignments RJ45 Connector (10BASE-T/100BASE-TX) Signal Name Input (I)/Output (O) Function TPO+ Transmit data+ TPO+ TPO- TPI+ TPO- Transmit data- TPI- TPI+ Receive data+ TPI- Receive data- – – Reserved LED Indications Indication Colour Description ON LINE Green On-line status indication •...
  • Page 86: Sip-gw4 Card (kx-tda3450)

    2.3.9 SIP-GW4 Card (KX-TDA3450) 2.3.9 SIP-GW4 Card (KX-TDA3450) Function 4-channel SIP gateway card. Compliant with RFC 3261, 3262, 3264, 3311, and 4028 protocols, and ITU-T G. 729A/B and G.711 CODEC methods. RJ45 DIP-SW (10BASE-T/100BASE-TX) Set the switch to the "ON" position. To LAN LEDs Data Circuit Terminating...
  • Page 87 2.3.9 SIP-GW4 Card (KX-TDA3450) Pin Assignments RJ45 Connector (10BASE-T/100BASE-TX) Signal Name Level [V] Function Transmit data (+) Transmit data (-) Receive data (+) Receive data (-) – – Reserved LED Indications Indication Colour Description Green Card status indication • ON: Normal •...
  • Page 88: Sip-dsp4 Card (kx-tda3451)

    2.3.10 SIP-DSP4 Card (KX-TDA3451) 2.3.10 SIP-DSP4 Card (KX-TDA3451) Function 4-channel VoIP DSP card. To be mounted on the SIP-GW4 card. Screws SIP-DSP4 Card SIP-GW4 Card Accessories and User-supplied Items Accessories (included): Screws ´ 2 User-supplied (not included): none Installation Manual...
  • Page 89: Information About The Extension Cards

    2.4.1 DLC4 Card (KX-TDA3171) 2.4 Information about the Extension Cards 2.4.1 DLC4 Card (KX-TDA3171) Function 4-port digital extension card for DPTs, DSS consoles, a Voice Processing System (VPS), and PT-interface CSs. RJ45 To extension Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Strap ´ 1 User-supplied (not included): RJ45 connector or RJ11 connector Notice The connector type may be RJ45 or RJ11 depending on the country/area.
  • Page 90 2.4.1 DLC4 Card (KX-TDA3171) RJ11 Connector Signal Name Function Data port (High) D2 D1 Data port (Low) – Reserved Installation Manual...
  • Page 91: Slc4 Card (kx-tda3173)

    2.4.2 SLC4 Card (KX-TDA3173) 2.4.2 SLC4 Card (KX-TDA3173) Function 4-port extension card for SLTs. RJ45 To extension Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Strap ´ 1 User-supplied (not included): RJ45 connector or RJ11 connector Note The connector type may be RJ45 or RJ11 depending on the country/area. Pin Assignments RJ45 Connector Signal Name...
  • Page 92: Dlc8 Card (kx-tda3172)

    2.4.3 DLC8 Card (KX-TDA3172) 2.4.3 DLC8 Card (KX-TDA3172) Function 8-port digital extension card for DPTs, DSS consoles, a VPS, and PT-interface CSs. RJ45 To extension Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Strap ´ 1 User-supplied (not included): RJ45 connector or RJ11 connector Notice The connector type may be RJ45 or RJ11 depending on the country/area.
  • Page 93: Slc8 Card (kx-tda3174)

    2.4.4 SLC8 Card (KX-TDA3174) 2.4.4 SLC8 Card (KX-TDA3174) Function 8-port extension card for SLTs. RJ45 To extension Accessories and User-supplied Items Accessories (included): Extension Bolt ´1, Strap ´ 1 User-supplied (not included): RJ45 connector or RJ11 connector Note The connector type may be RJ45 or RJ11 depending on the country/area. Pin Assignments RJ45 Connector Signal Name...
  • Page 94: Ip-ext4 Card (kx-tda3470)

    2.4.5 IP-EXT4 Card (KX-TDA3470) 2.4.5 IP-EXT4 Card (KX-TDA3470) Function 4-channel VoIP extension card. Compliant with Panasonic proprietary protocol, and ITU-T G.729A and G.711 CODEC methods. RJ45 LEDs To LAN Accessories and User-supplied Items Accessories (included): Ferrite core ´ 1, Extension Bolt ´ 1, Strap ´ 1...
  • Page 95 2.4.5 IP-EXT4 Card (KX-TDA3470) LED Indications Indication Colour Description ON LINE Green On-line status indication • ON: At least one port is in use (an IP-PT is connected) • OFF: No ports are in use (no IP-PTs are connected) Note If the LINK indicator is OFF, the ON LINE indicator will also be OFF.
  • Page 96: Information About The Other Cards

    2.5.1 DPH4 Card (KX-TDA3161) 2.5 Information about the Other Cards 2.5.1 DPH4 Card (KX-TDA3161) Function 4-port doorphone card for 4 doorphones, 4 door openers or external relays, and 4 external sensors. 10-pin 8-pin To external sensors Telephone Line Cord To door openers/ external relays To doorphones Accessories and User-supplied Items...
  • Page 97 2.5.1 DPH4 Card (KX-TDA3161) Pin Assignments RJ45 Connector Signal Name Function Doorphone 2 transmit com1 com3 Doorphone 1 transmit com2 com4 com1 Doorphone 1 receive com2 Doorphone 2 receive Doorphone 4 transmit Doorphone 3 transmit com3 Doorphone 3 receive com4 Doorphone 4 receive –...
  • Page 98 2.5.1 DPH4 Card (KX-TDA3161) 10-pin Terminal Block Signal Name Function OP1b (RL1b) Door opener 1 (Relay 1) OP1b (RL1b) OP1a (RL1a) OP1a (RL1a) Door opener 1 com (Relay 1 com) OP2b (RL2b) OP2a (RL2a) OP3b (RL3b) OP2b (RL2b) Door opener 2 (Relay 2) OP3a (RL3a) OP4b (RL4b) OP2a (RL2a)
  • Page 99: Dph2 Card (kx-tda3162)

    2.5.2 DPH2 Card (KX-TDA3162) 2.5.2 DPH2 Card (KX-TDA3162) Function 2-port doorphone card for 2 German-type doorphones, 2 door openers, 4 external sensors, and 4 external relays. RJ45 10-pin 8-pin Telephone Line Cord To external sensors To external relays To doorphones/ door openers Accessories and User-supplied Items Extension Bolt ´...
  • Page 100 2.5.2 DPH2 Card (KX-TDA3162) Pin Assignments RJ45 Connector Proprietary Standard Function Signal Name Signal Name OP1b TO b (1) Door opener 1 OP1b OP2b OP1a OP2a Path_1b Path_2b OP1a TO a (1) Door opener 1 com Path_1a Path_2a Call_1b Call_2b Call_1a Call_2a Path_1b...
  • Page 101 2.5.2 DPH2 Card (KX-TDA3162) 10-pin Terminal Block Signal Name Function RL1b Relay 1 RL1b RL1a RL1a Relay 1 com RL2b RL2a RL3b RL2b Relay 2 RL3a RL4b RL2a Relay 2 com RL4a RL3b Relay 3 RL3a Relay 3 com RL4b Relay 4 RL4a Relay 4 com...
  • Page 102: Echo8 Card (kx-tda3166)

    2.5.3 ECHO8 Card (KX-TDA3166) 2.5.3 ECHO8 Card (KX-TDA3166) Function 8-channel card for echo cancellation during conferences. Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Screw ´ 1 User-supplied (not included): none Note To establish a conference call involving 6 to 8 parties, install an ECHO8 card and enable echo cancellation for conferences using the Maintenance Console.
  • Page 103: Msg2 Card (kx-tda3191)

    2.5.4 MSG2 Card (KX-TDA3191) 2.5.4 MSG2 Card (KX-TDA3191) Function 2-channel message card. Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Screw ´ 1 User-supplied (not included): none Installation Manual...
  • Page 104: Svm2 Card (kx-tda3192)

    2.5.5 SVM2 Card (KX-TDA3192) 2.5.5 SVM2 Card (KX-TDA3192) Function 2-channel simplified voice message card for Built-in Simplified Voice Message feature. Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Screw ´ 1 User-supplied (not included): none Installation Manual...
  • Page 105: Esvm2 Card (kx-tda3194)

    2.5.6 ESVM2 Card (KX-TDA3194) 2.5.6 ESVM2 Card (KX-TDA3194) Function 2-channel simplified voice message card for Built-in Simplified Voice Message feature. Also supports MSG card features. Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Screw ´ 1 User-supplied (not included): none Installation Manual...
  • Page 106: Ext-cid Card (kx-tda3168)

    2.5.7 EXT-CID Card (KX-TDA3168) 2.5.7 EXT-CID Card (KX-TDA3168) Function Sends Caller ID signals to extension ports. Accessories and User-supplied Items Accessories (included): Extension Bolt ´ 1, Screw ´ 1 User-supplied (not included): none Installation Manual...
  • Page 107: Mec Card (kx-tda3105)

    2.5.8 MEC Card (KX-TDA3105) 2.5.8 MEC Card (KX-TDA3105) Function Memory expansion card to increase system data storage space, double the number of DPTs (using Digital XDP connection), and enable Broadcasting, display language selection for VM Menu, and Call Billing for Guest Room features.
  • Page 108: Rmt Card (kx-tda3196)

    2.5.9 RMT Card (KX-TDA3196) 2.5.9 RMT Card (KX-TDA3196) Function Analogue modem card for remote communication with the PBX. ITU-T V.90 support. To be installed in the RMT slot. RMT Card RMT Slot Accessories and User-supplied Items Accessories (included): none User-supplied (not included): none CAUTION Make sure to insert the RMT card between the guide rails until it locks into the RMT slot.
  • Page 109: Connection Of Extensions

    2.6.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) 2.6 Connection of Extensions 2.6.1 Maximum Cabling Distances of the Extension Wiring (Twis- ted Cable) Cable Maximum Distance PT-interface CS ø 0.4 mm: 222 m ø 0.5 mm: 347 m ø...
  • Page 110 2.6.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable) "ü" indicates that the extension card or Super Hybrid Ports support the terminal. Installation Manual...
  • Page 111: Parallel Connection Of The Extensions

    2.6.2 Parallel Connection of the Extensions 2.6.2 Parallel Connection of the Extensions Any SLT can be connected in parallel with an APT or a DPT as follows. Note In addition to an SLT, an answering machine, a fax machine or a modem (PC) can be connected in parallel with an APT or a DPT.
  • Page 112 2.6.2 Parallel Connection of the Extensions Using a Modular T-Adaptor To a Super Hybrid Port Modular T-Adaptor 2-conductor wiring cord Connect pins "T" and "R". 4-conductor wiring cord Connect pins "D1" and "D2". Using an EXtra Device Port With KX-DT300 Series DPT (except KX-DT321) To a Super Hybrid Port 2-conductor wiring cord 4-conductor wiring cord...
  • Page 113 2.6.2 Parallel Connection of the Extensions With KX-T7600 Series DPT (except KX-T7665) To a Super Hybrid Port 2-conductor wiring cord 4-conductor wiring cord Connect pins "T" and "R". Connect pins "T", "R", "D1" and "D2". TO MAIN UNIT / PABX TO TEL To a Super Hybrid Port To SLT...
  • Page 114: Digital Extra Device Port (digital Xdp) Connection

    2.6.3 Digital EXtra Device Port (Digital XDP) Connection 2.6.3 Digital EXtra Device Port (Digital XDP) Connection A DPT can be connected to another DPT on the Digital XDP connection. In addition, if the DPT is connected to a Super Hybrid Port, it can also have an SLT connected in Parallel mode or XDP mode. Note •...
  • Page 115 2.6.3 Digital EXtra Device Port (Digital XDP) Connection Using an EXtra Device Port To DLC4/DLC8 card 4-conductor wiring cord To a Super Hybrid Port Connect pins "T", "R", 2-conductor wiring cord (for connection of SLT) "D1" and "D2". Connect pins "T" and "R". 4-conductor wiring cord Connect pins "T", "R", "D1"...
  • Page 116 2.6.3 Digital EXtra Device Port (Digital XDP) Connection With KX-T7600 Series DPT (except KX-T7600E Series) Using a Modular T-Adaptor To DLC4/DLC8 card Modular To a Super Hybrid Port T-Adaptor (for connection of SLT) 2-conductor wiring cord Connect pins "T" and "R". 4-conductor wiring cord Connect pins "D1"...
  • Page 117 2.6.3 Digital EXtra Device Port (Digital XDP) Connection Using an EXtra Device Port To DLC4/DLC8 card 4-conductor wiring cord To a Super Hybrid Port Connect pins "T", "R", 2-conductor wiring cord (for connection of SLT) "D1" and "D2". Connect pins "T" and "R". 4-conductor wiring cord Connect pins "T", "R", "D1"...
  • Page 118 2.6.3 Digital EXtra Device Port (Digital XDP) Connection With KX-T7600E Series DPT Using a Modular T-Adaptor To DLC4/DLC8 card Modular To a Super Hybrid Port T-Adaptor (for connection of SLT) 2-conductor wiring cord Connect pins "T" and "R". 4-conductor wiring cord Connect pins "D1"...
  • Page 119 2.6.3 Digital EXtra Device Port (Digital XDP) Connection Using an EXtra Device Port Connecting to a Slave DPT To DLC4/DLC8 card To a Super Hybrid Port 4-conductor wiring cord (for connection of SLT) Connect pins "T", "R", 2-conductor wiring cord "D1"...
  • Page 120 2.6.3 Digital EXtra Device Port (Digital XDP) Connection Connecting to a Master DPT To DLC4/DLC8 card To a Super Hybrid Port 4-conductor wiring cord (for connection of SLT) Connect pins "D1" and "D2". 4-conductor wiring cord Connect pins "T", "R", "D1"...
  • Page 121: First Party Call Control Cti Connection

    2.6.4 First Party Call Control CTI Connection 2.6.4 First Party Call Control CTI Connection CTI connection between a PC and a KX-DT300 series/KX-T7633/KX-T7636 DPT provides first party call control. The CTI connection is made via a USB interface (version 2.0), and uses the TAPI 2.1 protocol. A USB Module must be connected to the DPTs.
  • Page 122: Connection Of Dect Portable Stations

    KX-TCA355 • KX-TD7590 • KX-TD7580 Notice The CSs for DECT are for connection to specified Panasonic PBXs only. Note For more details about the PS, refer to the Operating Instructions of the PS. Required Distances between Equipment CAUTION • Maintain the distances listed below between equipment in order to prevent noise, interference or the disconnection of a conversation.
  • Page 123 2.7.1 Overview Item Description Frequency Band 1880 MHz to 1900 MHz Number of Carriers Carrier Spacing 1728 kHz Bit Rate 1152 kbps Carrier Multiplex TDMA, 24 (Tx12, Rx12) slots per frame Frame Length 10 ms Modulation Scheme GFSK Roll-off factor=0.5 50 % roll-off in the transmitter Data Coding for Modulator Differential Coding...
  • Page 124: Procedure Overview

    2.7.2 Procedure Overview 2.7.2 Procedure Overview When connecting the wireless system, use extreme care in conducting the site survey. Site surveys can be conducted using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590 PS. An incorrectly performed site survey can result in poor service area, frequent noise, and disconnection of calls. 1.
  • Page 125 2.7.2 Procedure Overview Make sure that adjacent CS coverage areas overlap where the radio signal strength level is "8" by at least 5 m. Make sure that the radio signal strength level is greater than "3" at any location within the service area required by the user.
  • Page 126: Site Planning

    2.7.3 Site Planning 2.7.3 Site Planning Choosing the best site for the CS requires careful planning and testing of essential areas. The best location may not always be convenient for installation. Read the following information before installing the unit. Understanding Radio Waves Characteristics of Radio Waves The transmission of radio waves and the CS coverage area depend on the structure and materials of the building.
  • Page 127 2.7.3 Site Planning Object Material Transmission Tendency Window Glass Radio waves usually penetrate them. Glass with wire net Radio waves can penetrate them, but tend to be reflected. Glass covered with Radio waves are weakened considerably when they penetrate heat-resistant film windows.
  • Page 128 2.7.3 Site Planning CS Coverage Area The example below shows the size of the coverage area of 1 CS if it is installed in an area with no obstacles. Note Radio signal strength levels are measured during the site survey (refer to "2.7.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590").
  • Page 129 2.7.3 Site Planning Where CS coverage areas overlap, the PS will start call handover to the next CS if the signal from one CS becomes weak. However, if a PS moves away from a CS and there are no CSs available for handover, the PS may go out of range and the call could be lost.
  • Page 130: Before Site Survey

    2.7.4 Before Site Survey 2.7.4 Before Site Survey Use the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590 PS to conduct the site survey. Note Display prompts for the site survey are only available in English. Checking the CS ID Number Check the CS ID number label attached to the CS. Assigning the CS ID Number to the PS Using the KX-TCA255/KX-TCA256/KX-TCA355 To enter letters...
  • Page 131 2.7.4 Before Site Survey Using the KX-TD7590 To enter letters INT' CS No. CS ID No. Press 1, 9, and POWER 0 to 7 0 to 9 and A to F for more than 5 seconds. To the Desired CS No. To the initial display Note To clear the CS ID number assigned to the PS, follow the procedure below:...
  • Page 132 2.7.4 Before Site Survey Setting and Installing the CS Temporarily for Site Survey Switch the Radio Signal Test switch from OFF to ON. Set the channel number switches as desired. Set the Power Supply Select switch as desired (KX-TDA0158CE only). KX-TDA0158CE Radio Signal Test Switch Power Supply Select Switch...
  • Page 133 2.7.4 Before Site Survey KX-TDA0141CE DIP Switch Channel Number Switch Keep this switch at the default "OFF" position. Otherwise, the CS will not function. Radio Signal Test Switch Channel 0 Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 Channel 9 Note If more than 1 CS is in Radio Signal Test mode, each CS must have a unique channel number.
  • Page 134 2.7.4 Before Site Survey KX-TDA0158CE KX-TDA0141CE Modular Modular Telephone Cord Telephone Cord (PSJA1017Z) Power Supply Adaptor Power Supply Adaptor (PSZZ1TDA0142) (PSZZ1TDA0142) To AC Adaptor (KX-A11)/ To AC Adaptor (KX-A11/KX-TCA1)/ Battery Box (PSZZTD142CE) Battery Box (PSZZTD142CE) Modular To a Super Hybrid Port, or DLC4/DLC8 card Install the CS temporarily for the site survey.
  • Page 135: Site Survey Using The Kx-tca255/kx-tca256/kx-tca355/kx-td7590

    2.7.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590 2.7.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/ KX-TD7590 The PS has a Radio Signal Test mode that monitors the state of the radio link to the CS for site survey. In Radio Signal Test mode, the frame loss and signal strength of a synchronous slot, and the signal strength of the other slots can be measured when the PS is monitoring the CS.
  • Page 136 2.7.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590 Measure the radio signal strength by moving towards and away from the CS. Move to the CS until the radio signal strength level becomes "12". Move away from the CS and identify the CS coverage area within which the radio signal strength level is greater than "8".
  • Page 137 2.7.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590 Overlap the CS coverage areas of at least 2 CSs at any location in the installation site. Channel no. 0 Channel no. 1 Channel no. 2 Channel no. 3 Make sure that the radio signal strength level is greater than "3" at any location in the service area required by the user.
  • Page 138 2.7.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590 Using the KX-TD7590 Log No. Press 1, 9, and POWER 0 to 9 for more than 5 seconds. To go to other slots To go to specific channel Channel No. Previous or Next 0 to 9 Clearing the Stored Scan Data When "CLEAR SCAN DATA"...
  • Page 139: After Site Survey

    2.7.6 After Site Survey 2.7.6 After Site Survey After obtaining the proper measurement results, exit Radio Signal Test mode before connecting the CS to the PBX. Hold down the POWER button on the PS until the PS is turned OFF. Disconnect the CS from the AC adaptor/battery box, Super Hybrid Port, or DLC card to stop supplying electricity.
  • Page 140: Connecting A Cell Station To The Pbx

    2.7.7 Connecting a Cell Station to the PBX 2.7.7 Connecting a Cell Station to the PBX Refer to the following examples to connect a CS to the PBX. KX-TDA0158CE Super Hybrid Port Cable Maximum Distance ø 0.4 mm: 222 m ø...
  • Page 141 2.7.7 Connecting a Cell Station to the PBX Super Hybrid Ports or DLC4 card (RJ45) Port No. Signal Name Pin No. CS (RJ45) Pin No. Signal Name Master Super Hybrid Ports or DLC4 card (RJ11) Port No. Signal Name Pin No. CS (RJ45) Pin No.
  • Page 142 2.7.7 Connecting a Cell Station to the PBX DLC8 card (RJ45) DLC8 Port No. Port No. Signal Name Pin No. CS 1 (RJ45) Signal Name Pin No. Master CS 2 (RJ45) Signal Name Pin No. Master Installation Manual...
  • Page 143 2.7.7 Connecting a Cell Station to the PBX CS 1 (RJ45) DLC8 card (RJ11) Signal Name Pin No. Port No. Signal Name Pin No. Master CS 2 (RJ45) Signal Name Pin No. Master Accessories and User-supplied Items for the CS Accessories (included): Screws ´...
  • Page 144 2.7.7 Connecting a Cell Station to the PBX KX-TDA0141CE Super Hybrid Port Cable Maximum Distance ø 0.4 mm: 222 m ø 0.5 mm: 347 m ø 0.6 mm: 500 m CAT 5: 347 m A Super Hybrid Port, or DLC4/DLC8 card (RJ45) Signal Name Pin No.
  • Page 145 2.7.7 Connecting a Cell Station to the PBX Modular Modular To a Super Hybrid Port, To a Super Hybrid Port, or DLC4/DLC8 card or DLC4/DLC8 card Pass the cable through the groove of the CS (in any direction depending on your preference). KX-TDA0158CE KX-TDA0141CE To a Super Hybrid Port,...
  • Page 146 2.7.7 Connecting a Cell Station to the PBX Registering the PS The PS must be registered to the PBX before it can be used. Programming of both the PS and PBX is required. A PT with multiline display (e.g., KX-T7636 6-line display) is required to perform the PBX system programming. Note For details about system programming using a PT, refer to "2.3.2 PT Programming"...
  • Page 147 2.7.7 Connecting a Cell Station to the PBX Using the KX-TD7590 Press POWER for 5 seconds. To register for the first time SELECT Select "INITIAL SETTING". To re-register If required SELECT SELECT System Lock Password Select Select "DECT- 4 digits "PS-PROGRAM".
  • Page 148 2.7.7 Connecting a Cell Station to the PBX Changing the Display Language of the PS Using the KX-TCA155/KX-TCA255/KX-TCA256/KX-TCA355 Press POWER Select Select for 2 seconds. "Setting Handset". "Display Option". Select Select the desired "Select Language". language. Using the KX-TD7590 SELECT SELECT Press POWER Select...
  • Page 149 2.7.7 Connecting a Cell Station to the PBX Using the KX-TCA155/KX-TCA255/KX-TCA256/KX-TCA355 Press POWER Select Select Select for 2 seconds. "Setting Handset". "Registration". "Cancel Base". Handset PIN C.Tone 4 digits Select Select "Base 1–4". "YES". Using the KX-TD7590 SELECT Press POWER Select "DECT- for 5 seconds.
  • Page 150: Wall Mounting

    2.7.8 Wall Mounting 2.7.8 Wall Mounting Mounting the KX-TDA0158CE WARNING • Make sure that the wall that the unit will be attached to is strong enough to support the unit (approx. 310 g). If not, it is necessary for the wall to be reinforced. •...
  • Page 151 2.7.8 Wall Mounting Reference for Wall Mounting (KX-TDA0158CE) Please copy this page and use as a reference for wall mounting. Install a screw here. 83 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.
  • Page 152 2.7.8 Wall Mounting Mounting the KX-TDA0141CE WARNING • Make sure that the wall that the unit will be attached to is strong enough to support the unit (approx. 310 g). If not, it is necessary for the wall to be reinforced. •...
  • Page 153 2.7.8 Wall Mounting Reference for Wall Mounting (KX-TDA0141CE) Please copy this page and use as a reference for wall mounting. Install a screw here. 71 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.
  • Page 154: Connection Of 2.4 Ghz Portable Stations

    2.8.1 Overview 2.8 Connection of 2.4 GHz Portable Stations 2.8.1 Overview Required Equipment and Maximum Number of Calls CSs determine the area covered by the wireless system. The number of calls that can be made simultaneously through each CS varies depending on the model, as follows: Connection Port/Card Maximum Calls Compatible PSs...
  • Page 155: Procedure Overview

    2.8.2 Procedure Overview 2.8.2 Procedure Overview When connecting the wireless system, use extreme care in conducting the site survey. An incorrectly performed site survey can result in poor service area, frequent noise, and disconnection of calls. 1. Investigate the installation site Refer to "2.8.3 Site Planning".
  • Page 156 2.8.2 Procedure Overview By walking away from the CS with the PS, check the radio signal strength. The radio signal strength weakens as you walk away from the CS. Map the CS coverage area at radio signal strength levels "3" and "8". Make sure that adjacent CS coverage areas overlap where the radio signal strength level is "8"...
  • Page 157: Site Planning

    2.8.3 Site Planning 2.8.3 Site Planning Choosing the best site for the CS requires careful planning and testing of essential areas. The best location may not always be convenient for installation. Read the following information before installing the unit. Understanding Radio Waves Characteristics of Radio Waves The transmission of radio waves and the CS coverage area depend on the structure and materials of the building.
  • Page 158 2.8.3 Site Planning Object Material Transmission Tendency Window Glass Radio waves usually penetrate them. Glass with wire net Radio waves can penetrate them, but tend to be reflected. Glass covered with Radio waves are weakened considerably when they penetrate heat-resistant film windows.
  • Page 159 2.8.3 Site Planning CS Coverage Area The example below shows the size of the coverage area of 1 CS if it is installed in an area with no obstacles. Note Radio signal strength levels are measured during the site survey (refer to "2.8.5 Site Survey"). Coverage Area Radio signal strength level is greater than "3".
  • Page 160 2.8.3 Site Planning Where CS coverage areas overlap, the PS will start call handover to the next CS if the signal from one CS becomes weak. However, if a PS moves away from a CS and there are no CSs available for handover, the PS may go out of range and the call could be lost.
  • Page 161: Before Site Survey

    2.8.4 Before Site Survey 2.8.4 Before Site Survey Setting and Installing the CS Temporarily for Site Survey Switch the Radio Signal Test switch from OFF to ON. Set the CS number switches as desired. Set the Power Supply Select switch as desired (KX-TDA0151 only). KX-TDA0151 CS no.
  • Page 162 2.8.4 Before Site Survey KX-TDA0141 DIP Switch CS Number Switch Keep this switch at the default "OFF" position. Otherwise, the CS will not function. Radio Signal Test Switch CS no. 1 CS no. 2 CS no. 3 CS no. 4 CS no.
  • Page 163 2.8.4 Before Site Survey KX-TDA0151 KX-TDA0141 Modular Modular Telephone Cord Telephone Cord Power Supply Adaptor Power Supply Adaptor (PSZZ1TDA0142) (PSZZ1TDA0142) To AC Adaptor (KX-A11/KX-TCA1)/ To AC Adaptor (KX-A11/KX-TCA1)/ Battery Box (PSZZTD142CE) Battery Box (PSZZTD142CE) Modular To a Super Hybrid Port, or DLC4/DLC8 card Install the CS temporarily for the site survey.
  • Page 164: Site Survey

    2.8.5 Site Survey 2.8.5 Site Survey The PS has a Radio Signal Test mode that monitors the state of the radio link to the CS. After installing the CSs temporarily, set the PS to Radio Signal Test mode and measure each CS coverage area. Then, record the results on the map of the installation site.
  • Page 165 2.8.5 Site Survey Measure the radio signal strength by moving towards and away from the CS. Move to the CS until the radio signal strength level becomes "12". Move away from the CS and identify the CS coverage area within which the radio signal strength level is greater than "8".
  • Page 166 2.8.5 Site Survey Overlap the CS coverage areas of at least 2 CSs at any location in the installation site. CS no. 1 CS no. 2 CS no. 3 CS no. 4 Make sure that the radio signal strength level is greater than "3" at any location in the service area required by the user.
  • Page 167 2.8.5 Site Survey Using the KX-TD7690 Display example: When there is scan data Scan Data No. NO.1 CS No.2 LEVEL: 9 Press 1, 9, and POWER 0 to 9 for more than 2 seconds. When there is no scan data NO.0 NOT SAVED To the Desired Scan Data No.
  • Page 168: After Site Survey

    2.8.6 After Site Survey 2.8.6 After Site Survey After obtaining the proper measurement results, exit Radio Signal Test mode before connecting the CS to the PBX. Hold down the POWER button on the PS until the PS is turned OFF. Disconnect the CS from the AC adaptor/battery box, Super Hybrid Port, or DLC card to stop supplying electricity.
  • Page 169: Connecting A Cell Station To The Pbx

    2.8.7 Connecting a Cell Station to the PBX 2.8.7 Connecting a Cell Station to the PBX Refer to the following example to connect a CS to the PBX. KX-TDA0151/KX-TDA0141 Super Hybrid Port Cable Maximum Distance ø 0.4 mm: 222 m ø...
  • Page 170 2.8.7 Connecting a Cell Station to the PBX Connecting the CS Connect the cable from a Super Hybrid Port or the DLC4/DLC8 card to the CS. KX-TDA0151 KX-TDA0141 Modular Modular To a Super Hybrid Port, To a Super Hybrid Port, or DLC4/DLC8 card or DLC4/DLC8 card Pass the cable through the groove of the CS (in any direction depending on your preference).
  • Page 171 2.8.7 Connecting a Cell Station to the PBX Registering the PS The PS must be registered to the PBX before it can be used. Programming of both the PS and PBX is required. A PT with multiline display (e.g., KX-T7636 6-line display) is required to perform the PBX system programming. Note For details about system programming using a PT, refer to "2.3.2 PT Programming"...
  • Page 172 2.8.7 Connecting a Cell Station to the PBX PS Registration [690] PS No. Extn. No. To the PS operation 001 to 028 1 to 4 digits below ENTER ENTER (HOLD) When the PS has not been registered yet When registering the PS for the first time, it is possible to select the desired language for the display. (You do not need to enter the PS system programming mode when registering for the first time.) Using the KX-TD7684/KX-TD7694 C.Tone...
  • Page 173 2.8.7 Connecting a Cell Station to the PBX Using the KX-TD7684/KX-TD7694 Select Choose "On/Off". "System Lock". System Lock Password System Lock Password 4 digits 4 digits C.Tone Using the KX-TD7680 Choose Select "Enable/Disable". "SYSTEM LOCK". System Lock Password System Lock Password ENABLE 4 digits 4 digits...
  • Page 174 2.8.7 Connecting a Cell Station to the PBX Setting the Personal Identification Number (PIN) for PS Registration To prevent registering the PS to a wrong PBX, a PIN for PS registration can be set to the PBX. Before registering the PS to the PBX, enter the PIN set to the PBX into the PS. By doing so, the PS will only be registered to the PBX with the matching PIN.
  • Page 175 2.8.7 Connecting a Cell Station to the PBX PS Termination Confirm the following before cancelling the PS registration: • The PS is turned on. • The PS is within range. [691] PS No. 001 to 028 ENTER ENTER If "Rejected" or "Time out" is displayed CLEAR To the PS operation...
  • Page 176: Wall Mounting

    2.8.8 Wall Mounting 2.8.8 Wall Mounting Mounting the KX-TDA0151 WARNING • Make sure that the wall that the unit will be attached to is strong enough to support the unit (approx. 310 g). If not, it is necessary for the wall to be reinforced. •...
  • Page 177 2.8.8 Wall Mounting Slide the wall mounting plate in the direction of the arrow until it clicks. KX-TDA0151 Hook the CS on the screw heads. KX-TDA0151 Washer Drive the screw to this point. CAUTION Make sure the cables are securely fastened to the wall. Installation Manual...
  • Page 178 2.8.8 Wall Mounting Reference for Wall Mounting (KX-TDA0151) Please copy this page and use as a reference for wall mounting. Install a screw here. 83 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.
  • Page 179 2.8.8 Wall Mounting Mounting the KX-TDA0141 WARNING • Make sure that the wall that the unit will be attached to is strong enough to support the unit (approx. 310 g). If not, it is necessary for the wall to be reinforced. •...
  • Page 180 2.8.8 Wall Mounting Reference for Wall Mounting (KX-TDA0141) Please copy this page and use as a reference for wall mounting. Install a screw here. 71 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.
  • Page 181: Connection Of Dect 6.0 Portable Stations

    2.9.1 Overview 2.9 Connection of DECT 6.0 Portable Stations 2.9.1 Overview Names and Locations of CS Antennas CS ID Number (ID: xxxxxxxxxx) LED Indications Indication Colour Description STATUS Green/Red CS status indication • OFF: Power Off • Green ON: Stand-by (no active calls) •...
  • Page 182 2.9.1 Overview Required Distances between Equipment Maintain the distances listed below between equipment in order to prevent noise, interference or the disconnection of a conversation. (The distance may vary depending on the environment.) Equipment Distance CS and office equipment such as a computer, telex, fax More than 2 m machine, etc.
  • Page 183: Procedure Overview

    2.9.2 Procedure Overview 2.9.2 Procedure Overview When connecting the wireless system, use extreme care in conducting the site survey. An incorrectly performed site survey can result in poor service area, frequent noise, and disconnection of calls. Notice • When installing the DECT 6.0 wireless system in an area where another wireless system (2.4 GHz) is already installed, it is necessary to reconduct the site survey to find the optimum position for the CS.
  • Page 184 2.9.2 Procedure Overview 4. Finish the site survey Refer to "2.9.6 After Site Survey". Turn off the PS. Stop supplying power, and return all DIP switches of each CS to the OFF position. 5. Connect the CS and PS to the PBX and test the operation Refer to "2.9.7 Connecting a Cell Station to the PBX".
  • Page 185: Site Planning

    2.9.3 Site Planning 2.9.3 Site Planning Choosing the best site for the CS requires careful planning and testing of essential areas. The best location may not always be convenient for installation. Read the following information before installing the unit. Understanding Radio Waves Characteristics of Radio Waves The transmission of radio waves and the CS coverage area depend on the structure and materials of the building.
  • Page 186 2.9.3 Site Planning Object Material Transmission Tendency Wall Concrete The thicker they are, the less radio waves pene- trate them. Ferroconcrete Radio waves can penetrate them, but the more iron there is, the more radio waves are reflected. Window Glass Radio waves usually penetrate them.
  • Page 187 2.9.3 Site Planning CS Coverage Area The example below shows the size of the coverage area of 1 CS if it is installed in an area with no obstacles. Note Radio signal strength levels are measured during the site survey (refer to "2.9.5 Site Survey"). Coverage Area Radio signal strength level is greater than "3".
  • Page 188 2.9.3 Site Planning Where CS coverage areas overlap, the PS will start call handover to the next CS if the signal from one CS becomes weak. However, if a PS moves away from a CS and there are no CSs available for handover, the PS may go out of range and the call could be lost.
  • Page 189: Before Site Survey

    2.9.4 Before Site Survey 2.9.4 Before Site Survey Use the KX-TD7685/KX-TD7695 PS to conduct the site survey. Note Display prompts for the site survey are only available in English. Checking the CS ID Number Check the CS ID number label attached to the CS. If the CS ID number label is not attached to the CS, check the CS ID number using the Maintenance Console.
  • Page 190 2.9.4 Before Site Survey KX-TDA0155 Channel 0 Channel 1 Channel 2 DIP Switch Channel 3 Channel Number Switch Power Supply Select Switch ON: From the AC Adaptor (KX-A11/KX- Channel 4 TCA1)/Battery Box (PSZZTD142CE) OFF: From the PBX Radio Signal Test Switch Installation Manual...
  • Page 191 2.9.4 Before Site Survey KX-TDA0158 Radio Signal Test Switch Power Supply Select Switch ON: From the AC Adaptor (KX-A11)/ Battery Box (PSZZTD142CE) OFF: From the PBX Channel Number Switch DIP Switch Channel 0 Channel 1 Channel 2 Channel 3 Channel 4 Note If more than 1 CS is in Radio Signal Test mode, each CS must have a unique channel number.
  • Page 192 2.9.4 Before Site Survey KX-TDA0155 KX-TDA0158 RJ11 Modular RJ45 Modular Telephone Cord Telephone Cord (PSJA1017Z) Power Supply Adaptor Power Supply Adaptor (PSZZ1TDA0142) (PSZZ1TDA0142) RJ11 Modular RJ11 Modular To AC Adaptor (KX-A11/KX-TCA1)/ To AC Adaptor (KX-A11)/ Battery Box (PSZZTD142CE) Battery Box (PSZZTD142CE) RJ11 Modular RJ45 Modular To PBX...
  • Page 193 2.9.4 Before Site Survey Install the CS temporarily for the site survey. Install the CS at least 2 m above the floor, and place the antennas so that they are pointing in directions that are 90 degrees apart (for antenna diversity), as follows: 45º...
  • Page 194: Site Survey

    2.9.5 Site Survey 2.9.5 Site Survey The PS has a Radio Signal Test mode that monitors the state of the radio link to the CS for site survey. In Radio Signal Test mode, the frame loss and signal strength of a synchronous slot, and the signal strength of the other slots can be measured when the PS is monitoring the CS.
  • Page 195 2.9.5 Site Survey Move away from the CS and identify the CS coverage area within which the radio signal strength level is greater than "3". Draw the area on the map. L:12 Channel no. 0 L:08 L:03 Radio Signal Strength Levels Level: 11 to 12 Better Level: 08 to 10...
  • Page 196 2.9.5 Site Survey Plan the CS coverage areas to meet for at least 2 CSs at any location in the installation site. Channel no. 0 Channel no. 1 Channel no. 2 Channel no. 3 Make sure that the radio signal strength level is greater than "3" at any location in the service area required by the user.
  • Page 197 2.9.5 Site Survey Referring to the Stored Scan Data Using the KX-TD7685/KX-TD7695 Log No. Press 1, 9, and POWER 0 to 9 for more than 2 seconds. To go to other slots To go to specific channel Channel No. Previous or Next 0 to 4 Clearing the Stored Scan Data Using the KX-TD7685/KX-TD7695...
  • Page 198: After Site Survey

    2.9.6 After Site Survey 2.9.6 After Site Survey After obtaining the proper measurement results, exit Radio Signal Test mode before connecting the CS to the PBX. Hold down the POWER button on the PS until the PS is turned OFF. Disconnect the CS from the AC adaptor/battery box or the PBX to stop supplying electricity.
  • Page 199: Connecting A Cell Station To The Pbx

    2.9.7 Connecting a Cell Station to the PBX 2.9.7 Connecting a Cell Station to the PBX Note When connecting both KX-TDA0155 and KX-TDA0158 CSs to the same card, the KX-TDA0158 CSs must be connected to lower-numbered pins on the card than the KX-TDA0155 CSs. Refer to the following examples to connect a CS to the PBX.
  • Page 200 2.9.7 Connecting a Cell Station to the PBX Note For details about the DLC4 card or DLC8 card, refer to "2.4.1 DLC4 Card (KX-TDA3171) " or "2.4.3 DLC8 Card (KX-TDA3172)". KX-TDA0158 Super Hybrid Port Cable Maximum Distance ø 0.4 mm: 222 m ø...
  • Page 201 2.9.7 Connecting a Cell Station to the PBX Super Hybrid Ports or DLC4 card (RJ45) Port No. Signal Name Pin No. CS (RJ45) Pin No. Signal Name Master Super Hybrid Ports or DLC4 card (RJ11) Port No. Signal Name Pin No. CS (RJ45) Pin No.
  • Page 202 2.9.7 Connecting a Cell Station to the PBX DLC8 DLC8 card (RJ45) Port No. Port No. Signal Name Pin No. CS 1 (RJ45) Signal Name Pin No. Master CS 2 (RJ45) Signal Name Pin No. Master Installation Manual...
  • Page 203 2.9.7 Connecting a Cell Station to the PBX CS 1 (RJ45) DLC8 card (RJ11) Signal Name Pin No. Port No. Signal Name Pin No. Master CS 2 (RJ45) Signal Name Pin No. Master Accessories and User-supplied Items for the CS Accessories (included): Screws ´...
  • Page 204 2.9.7 Connecting a Cell Station to the PBX Connecting the CS Connect the cable from the PBX to the CS. KX-TDA0155 KX-TDA0158 RJ11 Modular RJ45 Modular To PBX To PBX Pass the cable through the groove of the CS (in any direction depending on your preference). KX-TDA0155 KX-TDA0158 To PBX...
  • Page 205 2.9.7 Connecting a Cell Station to the PBX Entering the System Programming Mode PT (Administrator Level) System Password for Administrator— Programming No. for PT Programming PROGRAM/ PAUSE = 1234 3 digits Note means default value throughout this section. Setting the Personal Identification Number (PIN) for PS Registration To prevent registering the PS to a wrong PBX, a PIN for PS registration can be set to the PBX.
  • Page 206 2.9.7 Connecting a Cell Station to the PBX When the PS has not been registered yet When registering the PS for the first time, it is possible to select the desired language for the display. (You do not need to enter the PS system programming mode when registering for the first time.) Using the KX-TD7685/KX-TD7695 If required C.Tone...
  • Page 207 2.9.7 Connecting a Cell Station to the PBX Using the KX-TD7685/KX-TD7695 Press POWER Select Select for 2 seconds. "Setting Handset". "System Option". If required System Lock Password 4 digits Select Select the desired "Cancel Base". base (Base 1–4). C.Tone Select "Yes". Testing the Operation Walk around the service area while having a conversation using a registered PS.
  • Page 208: Wall Mounting

    2.9.8 Wall Mounting 2.9.8 Wall Mounting Mounting the KX-TDA0155/KX-TDA0158 WARNING • Make sure that the wall that the unit will be attached to is strong enough to support the unit (approx. 310 g). If not, it is necessary for the wall to be reinforced. •...
  • Page 209 2.9.8 Wall Mounting Hook the CS on the screw heads. KX-TDA0155 KX-TDA0158 Washer Washer Drive the screw Drive the screw to this point. to this point. Place the antennas so that they are pointing in directions that are 90 degrees apart (for antenna diversity), as follows: 45º...
  • Page 210 2.9.8 Wall Mounting Reference for Wall Mounting Please copy this page and use as a reference for wall mounting. Install a screw here. 83 mm 100 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.
  • Page 211: Connection Of Doorphones, Door Openers, External Sensors, And External Relays

    2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays 2.10 Connection of Doorphones, Door Openers, Ex- ternal Sensors, and External Relays 2.10.1 Connection of Doorphones, Door Openers, External Sen- sors, and External Relays A maximum of 4 doorphones (KX-T30865/KX-T7765), 4 door openers or external relays, and 4 external sensors can be connected to the PBX with a DPH4 card.
  • Page 212 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Note for KX-T7765 Users When loosening/tightening the screw, do not scratch the cabinet wall with the driver shaft. Cabinet Wall Pass the wires through the hole in the base cover, and attach the base cover to a wall using 2 screws. Screw To 8-pin terminal block Note...
  • Page 213 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Connection of Doorphones to the DPH4 Card with RJ45 Connectors Unlatch the cover of the terminal box by inserting a flathead screwdriver into the openings and levering the cover open. Follow the order indicated by the numbers 1 to 4. Connect the wires of doorphones to the terminal box.
  • Page 214 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Cut and remove the appropriate parts from the cover depending on your preference. Make sure to run the connected wires through the opening. Then, close the cover. Installation Manual...
  • Page 215 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Connect the terminal box to the DPH4 card in the PBX using the telephone line cords included with the card. To DPH4 card Telephone Line Cord To doorphones Connection of Doorphones to the DPH4 Card with RJ11 Connectors Connect the DPH4 card to the terminal boxes using the telephone line cords included with the card.
  • Page 216 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Connect the wires of doorphones 2 and 4 to the yellow and black screws on the terminal box. To DPH4 card Telephone Line Cord Terminal Box (included with the card ) Black Yellow Green...
  • Page 217 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Connect the wires of door openers and doorphones to the terminal box. For details about pin assignments for the DPH2 card, refer to "2.5.2 DPH2 Card (KX-TDA3162)". Terminal Box (included with the card) To doorphones/door openers Pin Assignments for Terminal Box...
  • Page 218 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Make sure to run the connected wires through it. Then, close the cover. Connect the terminal box to the DPH2 card in the PBX using the telephone line cords included with the card.
  • Page 219 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays While pressing down on the hole at the top of the terminal block using a screwdriver, insert the wire into the side hole as shown below. Repeat this procedure for other door openers, external sensors, and external relays.
  • Page 220 2.10.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays Connection of External Sensors and External Relays to DPH2 Card Use 8-pin and 10-pin terminal block (included with the card) for connection. While pressing down on the hole at the top of the terminal block using a screwdriver, insert the wire into the side hole as shown below.
  • Page 221: Connection Of Peripherals

    2.11.1 Connection of Peripherals 2.11 Connection of Peripherals 2.11.1 Connection of Peripherals Cable Maximum Distance ø 0.4 mm: 10 m ø 0.5 mm: 10 m ø 0.6 mm: 10 m CAT 5: 10 m BGM/ Music on Hold Cable Maximum Distance Pager: ø...
  • Page 222 2.11.1 Connection of Peripherals CAUTION An External Paging Jack is an SELV port and should only be connected to an approved SELV device, or in Australia, via the Line Isolation Unit with the Telecommunications Compliance Label. PC/Printer (via RS-232C) The PBX is equipped with an RS-232C interface. This interface provides communication between the PBX and the user-supplied devices such as PC or line printers.
  • Page 223 2.11.1 Connection of Peripherals For connecting a printer/PC with a 25-pin RS-232C connector PBX (9-pin) Printer/PC (25-pin) Circuit Type Signal Signal Circuit Type Pin No. Pin No. (EIA) Name Name (EIA) RD (RXD) SD (TXD) RD (RXD) ER (DTR) SD (TXD) ER (DTR) DR (DSR) RS (RTS)
  • Page 224 2.11.1 Connection of Peripherals CAUTION To protect the system, keep the following in mind: Make sure that both connector cases (frame ground) of the USB cable are conductive. If they are not conductive, make sure that both connector cases of the cable are firmly connected. If this is not possible, connect the frame of the PBX to the frame of the PC/CTI server using an earthing wire in order to prevent difference in the electrical potentials.
  • Page 225: Power Failure Connections

    2.12.1 Power Failure Connections 2.12 Power Failure Connections 2.12.1 Power Failure Connections When the power supply to the PBX fails, power failure transfer (PFT) will switch from the current connection to the Power Failure Connection. Refer to "2.4.1 Power Failure Transfer" in the Feature Guide for further information.
  • Page 226 2.12.1 Power Failure Connections Switch Settings Switch Type Usage and Status Definition PFT Setting Set all DIP switches to "ON" positions to use LINE 1 and LINE 2 as a PFT port. LINE 1: Power Failure LINE (NT1) LINE 2: Power Failure EXTN (extension) RJ45 Connector LINE 1 Pin Assignments Signal Name Level [V]...
  • Page 227: Starting The Pbx

    2.13.1 Starting the PBX 2.13 Starting the PBX 2.13.1 Starting the PBX CAUTION • Before touching the System Initialise Switch, discharge static electricity by touching ground or wearing an earthing strap. • Once you have started the PBX and if you unplug the PBX, do not perform the following procedures to start the PBX again.
  • Page 228 2.13.1 Starting the PBX Plug the DC connector of the AC adaptor into DC IN 1. DC IN 1 DC Connector AC Adaptor Note • The AC adaptor supplied with the PBX must be connected to DC IN 1. If an AC adaptor is connected only to DC IN 2, the PBX will not start.
  • Page 229 The DPTs should show the time as 01:00. The data of the IP-GW4 card will not be initialised. IMPORTANT Use only the AC adaptor (Panasonic PSLP1244/Panasonic PSLP1434) and AC cord supplied with the PBX, or the Additional AC Adaptor (KX-A236). Installation Manual...
  • Page 230: Turning Off The Pbx

    2.13.1 Starting the PBX LED Indications Indication Colour Description Green PBX status indication • OFF: Power Off (includes normal reset) • ON: Power On and running (on-line) • Flashing (60 times per minute): Starting up • Flashing (120 times per minute): Starting up or resetting with: •...
  • Page 231: Guide For The Maintenance Console

    Section 3 Guide for the Maintenance Console Explains the installation procedure, structure, and basic information of the Maintenance Console. Installation Manual...
  • Page 232: Overview

    3.1.1 Overview 3.1 Overview 3.1.1 Overview The Maintenance Console is designed to serve as an overall system programming reference for the PBX. To programme and administer the PBX by PC, you need to install the Maintenance Console onto the PC. This manual describes overview and installation of the Maintenance Console only.
  • Page 233: Pc Connection

    3.2.1 PC Connection 3.2 PC Connection 3.2.1 PC Connection Serial Interface Connection RS-232C Port To COM Port To USB Port USB Port CAUTION To protect the system, keep the following in mind: Make sure that both connector cases (frame ground) of the RS-232C cross cable (shielded cable)/USB cable are conductive.
  • Page 234 3.2.1 PC Connection LAN Connection via IP-GW4 Card RJ45 Switching Hub To network port Note For pin assignments and maximum cabling distance, refer to "2.3.8 IP-GW4 Card (KX-TDA3480)". External Modem Connection RS-232C Port (9-pin) Modem To RS-232C port (25-pin) To trunk/PBX extension port assigned as the trunk destination PBX (9-pin) External Modem (25-pin)
  • Page 235 3.2.1 PC Connection Make sure that both connector cases (frame ground) of the RS-232C straight cable (shielded cable) are conductive. If they are not conductive, make sure that both connector cases of the cable are firmly connected. If this is not possible, connect the frame of the PBX to the frame of the PC using an earthing wire in order to prevent difference in the electrical potentials.
  • Page 236: Installation Of The Maintenance Console

    3.3.1 Installing and Starting the Maintenance Console 3.3 Installation of the Maintenance Console 3.3.1 Installing and Starting the Maintenance Console System Requirements Required Operating System • Microsoft Windows XP or Windows Vista Business ® ® ® Minimum Hardware Requirements • HDD: 100 MB of available hard disk space Recommended Display Settings •...
  • Page 237 3.3.1 Installing and Starting the Maintenance Console Starting the Maintenance Console and Assigning the Basic Items (Quick Setup) When you start the Maintenance Console with the Installer Level Programmer Code and connect to the PBX for the first time after initialisation (with the factory default setting), Quick Setup will launch automatically. During Quick Setup, you will set up the basic items.
  • Page 238 3.3.1 Installing and Starting the Maintenance Console When country/area data do not match: Click OK to replace the country/area data of the PBX. Replacement may take several minutes to complete. Follow the procedure described in "2.13.1 Starting the PBX" and restart the PBX. Repeat step 5 to reconnect the Maintenance Console to the PBX.
  • Page 239: Troubleshooting

    Section 4 Troubleshooting This section provides information on the PBX and telephone troubleshooting. Installation Manual...
  • Page 240: Troubleshooting

    4.1.1 Installation 4.1 Troubleshooting 4.1.1 Installation PROBLEM PROBABLE CAUSE SOLUTION Extension does not operate. Bad extension card. • Exchange the card for a known working one. Bad connection between the • Take the telephone and plug it into the PBX and telephone. same extension port using a short tele- phone cord.
  • Page 241: Connection

    4.1.2 Connection 4.1.2 Connection Connection between the PBX and a PT: CAUSE SOLUTION Can you dial The T/R is connected to the D1/D2. Use the correct cord (the an extension? inner 2 wires are for T/R and the outer 2 wires are for D1/D2).
  • Page 242 4.1.2 Connection Connection between the trunk and the PBX: CAUSE SOLUTION (Continued from the Trunk is connected to the T2/T1. Reconnect the trunk to previous page.) the T1/R1 or T2/R2 of the telephone jack using 2-conductor wiring. Can you dial out on a Trunk trunk?
  • Page 243: Operation

    4.1.3 Operation 4.1.3 Operation PROBLEM PROBABLE CAUSE SOLUTION • • • When using the speaker- The HANDSET/HEAD- When the headset is not used, set the phone on an APT, nothing SET selector is set to the HANDSET/HEADSET selector to the is audible.
  • Page 244 4.1.3 Operation PROBLEM PROBABLE CAUSE SOLUTION • • • Cannot register the PS. Wrong Personal Identifi- Enter the PIN set to the PBX into the PS. cation Number (PIN) is registered to the PS. • • CS is not connected prop- Make sure that the cable is connected erly.
  • Page 245: Using The Reset Button

    4.1.4 Using the Reset Button 4.1.4 Using the Reset Button If the PBX does not operate properly, use the Reset Button. Before using the Reset Button, try the system feature again to confirm whether there definitely is a problem or not. CAUTION In order to avoid possible corruption of data on the SD Memory Card, please ensure that the "SD ACCESS"...
  • Page 246: Troubleshooting By Error Log

    4.1.5 Troubleshooting by Error Log 4.1.5 Troubleshooting by Error Log When a major system error occurs in the PBX, the ALARM indicator on the front of the cabinet turns on red, and the system logs the error information. Error Log Display Format Below is the display format of the error log.
  • Page 247 4.1.5 Troubleshooting by Error Log Item Description Sub Code The 5-digit sub code of the relevant hardware (1XXYY). • 1: Cabinet number • XX: Slot number 00 to 11 (00: MPR card slot; 01: Super hybrid ports; 02 to 11: Slots for optional service cards) •...
  • Page 248 4.1.5 Troubleshooting by Error Log Installation Manual...
  • Page 249: Appendix

    Section 5 Appendix Installation Manual...
  • Page 250: Revision History

    5.1.1 PSMPR Software File Version 1.1xxx 5.1 Revision History 5.1.1 PSMPR Software File Version 1.1xxx New Options • System Components Table – 3-Port DID Card (DID3) KX-TDA3182 – 2-Port Analogue Trunk Card (LCOT2) KX-TDA3183 – Memory Expansion Card (MEC) KX-TDA3105 Changed Contents •...
  • Page 251: Psmpr Software File Version 2.0xxx

    5.1.2 PSMPR Software File Version 2.0xxx 5.1.2 PSMPR Software File Version 2.0xxx New Options • System Components Table – 1-Port BRI Card (BRI1) KX-TDA3283 – SD Memory Card for Software Upgrade KX-TDA3820 – SD Memory Card for Software Upgrade to Enhanced Version KX-TDA3920 Changed Contents •...
  • Page 252: Psmpr Software File Version 2.2xxx

    5.1.3 PSMPR Software File Version 2.2xxx 5.1.3 PSMPR Software File Version 2.2xxx New Options • System Components Table – 2-Channel Simplified Voice Message Card (SVM2) KX-TDA3192 – 1-Port BRI Card (BRI1) KX-TDA3283 – SD Memory Card for Software Upgrade KX-TDA3820 –...
  • Page 253: Psmpr Software File Version 3.0xxx

    5.1.4 PSMPR Software File Version 3.0xxx 5.1.4 PSMPR Software File Version 3.0xxx New Options • System Components Table – E-1 Trunk Card (E1) KX-TDA3188 Changed Contents • 1.4.3 System Capacity • 3.3.1 Installing and Starting the Maintenance Console Installation Manual...
  • Page 254: Psmpr Software File Version 4.0xxx

    5.1.5 PSMPR Software File Version 4.0xxx 5.1.5 PSMPR Software File Version 4.0xxx New Options • System Components Table – 4-Channel SIP Trunk Card (SIP-GW4) KX-TDA3450 – 4-Channel VoIP DSP Card (SIP-DSP4) KX-TDA3451 – 4-Channel VoIP Extension Card (IP-EXT4) KX-TDA3470 Changed Contents •...
  • Page 255: Psmpr Software File Version 5.0xxx

    5.1.6 PSMPR Software File Version 5.0xxx 5.1.6 PSMPR Software File Version 5.0xxx New Options • System Components Table – 2-Channel Simplified Voice Message Card (ESVM2) KX-TDA3194 – 2-Channel Cell Station Unit Using a Super Hybrid Port or a DLC Card for 2.4 KX-TDA0151 GHz Portable Station –...
  • Page 256 5.1.6 PSMPR Software File Version 5.0xxx Installation Manual...
  • Page 257: Index

    Index Installation Manual...
  • Page 258 Index Connector Types Numerics Cover, Closing 1-Port BRI Card (KX-TDA3283) 24, 81 Cover, Opening 2-Channel Message Card (KX-TDA3191) 23, 103 CS (for 2.4 GHz Portable Station) 2-Channel Simplified Voice Message Card CS (for DECT 6.0 Portable Station) (KX-TDA3192) 24, 104 CS (for DECT Portable Station) 2-Channel Simplified Voice Message Card CTI Server Connection (via USB version 2.0)
  • Page 259 23, 92 KX-TDA3173 (4-Port Single Line Telephone Extension Card) 23, 91 Pager KX-TDA3174 (8-Port Single Line Telephone Extension Panasonic Proprietary Telephones, Compatible Card) 23, 93 Panasonic Proprietary Telephones, Incompatible KX-TDA3180 (4-Port Analogue Trunk Card) 23, 69 Parallel Connection of the Extensions...
  • Page 260 Trunk, Maximum Number Turning off the PBX Unpacking VoIP Line, Maximum Number Wall Mounting (AC Adaptor) Wall Mounting (CS) 150, 176 Wall Mounting (KX-TDA30) Wall Mounting Reference (AC Adaptor) Wall Mounting Reference (CS) Wall Mounting Reference (KX-TDA30) Wiring Precautions Installation Manual...
  • Page 261 Install a Install a screw here. screw here. 130 mm Reference for Wall Mounting Note Make sure to set the print size to correspond with the size of this page. If the dimensions of the paper output still deviate slightly from the measurements indicated here, use the measurements indicated here.
  • Page 262 Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. Declarations of Conformity for the relevant Panasonic products described in this manual are available for download by visiting: http://www.doc.panasonic.de...
  • Page 263 Notes Installation Manual...
  • Page 264 Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. Panasonic Communications Co., Ltd. 2005...

Comments to this Manuals

Symbols: 0
Latest comments:
