Replacing Node Board Processors

!
!
007-5483-001
Caution: When handling the processor, avoid placing direct pressure on the label area
of the fan.
Caution: Do not place the node board on a conductive surface. A conductive surface can
damage the BIOS battery and prevent the system from booting. Always place the node
board on an ESD-safe worksurface.
1. Remove the graphics card in accordance with the instructions on
2. Remove the air baffles from the chassis (refer to
Screws
Figure 3-16 Node Board Removal
3. Remove the heatsink assemblies
4. Press the load lever down and away from the retention clasp to release the load
plate from its locked position.
Hardware Replacement Procedures
page
Figure 3-16).
Air baffle
69.
75
