System Disk Drives
007-5483-001
The system disk drive are controlled by the SATA ports on the node board (refer to
Figure 2-7
on
page
26. The following system disk drive options are supported by the
SGI Virtu VN200 (refer to
•
2.5-in, 80 GB, 7200 RPM SATA
•
2.5-in, 120 GB, 7200 RPM SATA
•
2.5-in, 160 GB, 7200 RPM SATA
Note: Shut down the operating system before replacing a disk drive. Disk drives can be
replaced while the system is powered on (hot-plugged).
•
To remove a disk drive, release the latch on the drive carrier assembly and slide the
drive out of the chassis.
•
To install a disk drive, slide the drive into the chassis and close the latch.
Figure 2-14
System Disk Drives
Figure
2-14):
Node Board
39
