Unpacking the Rack

!
!
007-5483-001
Ensure that the temperature of the rack is acclimated to the installation environment and
that the system crate is stable, and in an upright position.
Refer to Figure 1-2 as you follow these steps; the numbered illustrations correspond to
the numbered steps. Ensure that the temperature of the rack is acclimated to the
installation environment and that the system container is stable, and in an upright
position.
Caution: Use eye protection when cutting the plastic bands on the shipping
container.Cutting the bands under high tension may cause them to snap back and strike
your face. Use caution when cutting the metal bands.
Caution: Use caution cutting the horizontal band holding the wooden ramp to the
shipping container, if the ramp is not supported, it may fall on you and cause serious
personal injury.
1. Use a sharp cutting tool to remove the band that secures the ramp to the shipping
container.
2. Position the ramp as shown in
base.
3. Remove the vertical bands that secure the load to the wooden base and remove top
corrugated cap, corrugated sleeves, foam top cushion and poly bag from the rack.
4. Remove the four M12 bolts securing the rack to the wooden base:
a. Open the front door and locate the two M12 bolts that secure the rack to the
large metal bracket.
b. Open the rear door, and disconnect the rear door ground wire.
c. Remove the rear door by lifting it off the two hinge pins.
d. Use a 3/4-in. socket and ratchet, remove the two M12 bolts securing the back of
the rack to the wooden base.
5. Remove four 9/16-in. hex head cap screws that secure the large metal bracket to the
front of the wooden base and remove the metal bracket.
Figure 1-2. Holes in the ramp fit over the pegs in the
Unpacking the Rack
