System Procedures

Removing TIM from a Processor

!
!
84
You should always remove the TIM from a processor before you remove it from the node
board.
Warning:
Always wear gloves when performing this procedure to avoid direct skin
contact with the TIM, which is a potentially toxic material.
Tools/Parts Required:
• Dry, lint-free cloth
• Lint-free cloth moistened with isopropyl alcohol
• Gloves
Caution: To prevent the processor from moving in its socket, ensure that the processor
load lever remains engaged while you perform the following procedure. If the processor
moves while you remove the TIM, the pins on the processor might be damaged.
Perform the following steps to remove the TIM from a processor:
1. Remove the heatsink from the socket.
