Removing the Air Baffles

007-5483-001
The air baffles deflect the airflow from the chassis fans across the node board and the
graphics card.
1. Remove the graphics card in accordance with the instructions on
2. Remove two screws on each side of the chassis (refer to
3. Lift the plate out of the chassis.
2 screws
Figure 3-14 Air Baffle Removal
Hardware Replacement Procedures
page
Figure 3-14).
Air baffle
69.
73
