Replacing the Control Panel
007-5483-001
The control panel is located at the front of the system (refer to
1.
Remove the disk drives or the front top cover to access the cable that connects to the
control panel.
2. Disconnect the cable connector that attaches to the control panel cable.
3. Remove the control panel from the chassis.
Connector
Control Panel Removal
Figure 3-19
Hardware Replacement Procedures
Figure
Control panel cable
Control
panel
3-19).
91
