FAIRCHILD PT-19
INTRODUCTION.
Thank you for choosing the PT-19 ARTF by SEAGULL MODELS. The PT-19 was designed with the
intermediate/advanced sport flyer in mind. It is a low-wing scale aeroplane which is easy to fly and
quick to assemble. The airframe is conventionally built using balsa, plywood make it stronger than
the average ARTF , yet the design allows the aeroplane to be kept light. You will find that most of the
work has been done for you already. The pushrods are pre-made to the correct lengths, the motor
mount has been fitted and the hinges are pre-installed and pinned for security. Flying the PT-19 is
simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your PT-19 . Use the parts listing below to identify all
parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable
of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU ASSUME ALL
RISK & RESPONSIBILITY.
If you are inexperienced with basic R/C flight we strongly recommend you contact your R/C supplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
procedures designed to help the new pilot on his way to successful R/C flight. They will also be able
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
- .46-.52 2-stroke engine.
- .52 4-stroke engine.
- 4-channel radio with six servos.
- Glow plug to suit engine.
- Propeller to suit engine.
- Protective foam rubber for radio
system.
- Silicone fuel line.
- Stick-on weights for balance
(If necessary).
TOOLS & SUPPLIES NEEDED.
- Thick cyanoacrylate glue.
- 30 minute epoxy.
- 6 minute epoxy.
- Hand or electric drill.
- Assorted drill bits.
- Modelling knife.
- Straight edge ruler.
- 2mm ball driver.
- Phillips head screwdriver.
- 220 grit sandpaper.
- 90° square or builder's triangle.
- Wire cutters.
- Masking tape & T-pins.
- Thread-lock / Paper towels.
2

Instruction Manual

PARTS LISTING.
FUSELAGE ASSEMBLY
* (1) Fuselage.
* (1) Pre-installed throttle pushrod &
tube.
* (1) Pre-installed servo tray.
* (1) Pre-installed rudder pushrod.
* (1) Pre-installed elevator pushrod.
WING ASSEMBLY.
* (1) Right wing half with pre-
installed aileron.
* (1) Left wing half with pre-installed
aileron.
* (2) Pre-installed plywood aileron
servo tray in each wing.
* (1) Plywood wing dihedral brace.
* (1) Covering strip for centre
section joint.
TAIL SECTION ASSEMBLY.
* (1) Vertical stabilizer with pre-
installed rudder.
* (1) Horizontal stabilizer with pre-
installed elevator halves.
