Suzuki DF 90 Service Manual page 18

1-14 GENERAL INFORMATION
Item
ELECTRICAL
Ignition timing
Over revolution limiter
CKP sensor resistance
CMP sensor resistance
Ignition coil resistance
Secondary
High tension cord resistance
Battery charge coil resistance
Battery charge coil output (12V)
Standard spark plug
Fuse amp. rating
Recommended battery
capacity (12V)
Fuel injector resistance
IAC valve resistance
IAT sensor / Cylinder temp. sensor
/ Ex- mani. temp. sensor
(Thermistor characteristic)
ECM main relay resistance
Starter relay coil resistance
PTT motor relay coil resistance
STARTER MOTOR
Max. continuous time of use
Motor output
Brush length
Commutator
undercut
Commutator
outside diameter
Commutator outside
diameter difference
Unit
Degrees
r/min
Ω
at 20°C
Ω
at 20°C
Ω
Primary
at 20°C
Ω
k at 20°C
Ω
k / m at 20°C
Ω
at 20°C
Watt
Type NGK
mm (in)
Gap
A
Ah (kC)
Ω
at 20°C
Ω
at 20°C
Ω
k at 25°C
Ω
at 20°C
Ω
at 20°C
Ω
at 20°C
Sec
k W
mm (in)
STD
mm (in)
Limit
mm (in)
STD
mm (in)
Limit
mm (in)
STD
mm (in)
Limit
mm (in)
STD
mm (in)
Limit
DF90T
BTDC 1° – BTDC 44°
168 – 252
1.9 – 2.5
No.2–No.3 : 18–34 (including H.T.cord and spark plug cap)
No.1–No.4 : 19–36 (including H.T.cord and spark plug cap)
Approx.16
0.16 – 0.24
BKR6E
0.7 – 0.8 (0.028 – 0.031)
Main fuse : 60
Sub fuse : 30
100 (360) or larger
11.0 – 16.5
1.8 – 2.3
80 – 120
80 – 120
3.0 – 4.5
16.0 (0.63)
12.0 (0.47)
0.5 – 0.8 (0.02 – 0.03)
0.2 (0.01)
29.0 (1.14)
28.0 (1.10)
0.05 (0.002)
0.40 (0.016)
Data
DF115T
BTDC 3° – BTDC 44°
6500
480
8 – 12
30
1.4
