Suzuki DF 90 Service Manual page 17

Item
CRANKSHAFT / CONROD
Conrod small end inside
diameter
Conrod big end oil
clearance
Conrod big end inside
diameter
Crank pin outside
diameter
Crank pin outside
diameter difference
(out of round and taper)
Conrod bearing
thickness
Conrod big end side
clearance
Conrod big end width
Crank pin width
Crankshaft center
journal runout
Crankshaft journal oil
clearance
Crankcase bearing
holder inside diameter
Crankshaft journal
outside diameter
Crankshaft journal
outside diameter
difference
(out of round and taper)
Crankshaft bearing
thickness
Crankshaft thrust play
Crankshaft thrust
bearing thickness
Unit
STD mm (in)
mm (in)
STD
mm (in)
Limit
mm (in)
STD
STD mm (in)
mm (in)
Limit
mm (in)
STD
mm (in)
STD
Limit mm (in)
mm (in)
STD
mm (in)
STD
Limit mm (in)
mm (in)
STD
mm (in )
Limit
mm (in)
STD
STD mm (in)
mm (in)
Limit
mm (in)
STD
STD mm (in)
mm (in)
Limit
STD mm (in)
GENERAL INFORMATION
Data
DF90T
21.003 – 21.011 (0.8269 – 0.8272)
0.020 – 0.040 (0.0008 – 0.0016)
0.065 (0.0026)
47.000 – 47.018 (1.8504 – 1.8511)
43.982 – 44.000 (1.7316 – 1.7323)
0.010 (0.0004)
1.484 – 1.502 (0.0584 – 0.0591)
0.100 – 0.250 (0.0039 – 0.0098)
0.350 (0.0138)
21.950 – 22.000 (0.8642 – 0.8661)
22.100 – 22.200 (0.8700 – 0.8740)
0.04 (0.002)
0.020 – 0.040 (0.0008 – 0.0016)
0.065 (0.0026)
62.000 – 62.018 (2.4409 – 2.4417)
57.994 – 58.012 (2.2832 – 2.2839)
0.010 (0.0004)
1.990 – 2.006 (0.0783 – 0.0790)
0.11 – 0.31 (0.004 – 0.012)
0.35 (0.014)
2.425 – 2.475 (0.0955 – 0.0974)
1-13
DF115T
