BRIEF INSTRUCTION

ARMING

• Press the button A of the radio control to lock the doors (if the vehicle has a central

locking system).

• The turn indicators will

blink twice.

• The buzzer will beep twice

(if activated).

• The protections activate

after a 40 seconds timer is

elapsed.

• The led will flash.

PROTECTION

When armed the system will generate an acoustic and visual 30 s alarm when the

bonnet, boot or one of the doors is opened. Articles with the volumetric sensor (ultrasonic

and/or hyperfrequency) will generate the alarm in case of intrusion.

The system remains activated at the end of the cycle.

Whith the system armed it will not be possible to cause the engine running (for system

with engine immobiliser).

INTERRUPTING AN ALARM IN PROGRESS

If the system generates an alarm, the siren can be disactivated by pressing button A

on the radio control once. The turn indicators will also stop blinking but the alarm

system remains armed. Thus, if the system is activated (siren sounding), press the

button twice to unlock the vehicle. The first pressure will stop the siren, the second

will disarm the system and unlock the doors.

DISARMING

• Press button A on the radio control to open the doors.

• The turn indicators will blink once.

• The buzzer will beep once (if activated).

• The protections disactivate immediately.

• The led will go off.

Note:

Note: If an alarm has occurred the buzzer and the turn indicators will give four signals

instead of one also if the buzzer is disarmed (refer to ALARM MEMORY section).

mod. 7777

mod. 7727

SPECIAL FUNCTIONS

AUTOMATIC ARMING (if activated)

If the unit is programmed with the automatic arming function, it will automatically

arm about 60 seconds after the driver's side door has been opened and in any case

255 seconds after the engine has been turned off.

The LED will flash.

The doors will not automatically lock.

If activation occurs, the engine will be immobilised. Press button A on the radio control

to disactivate the system. The LED will go out to confirm that the system has been

disactivated.

INHIBITION OF THE AUTOMATIC ARMING FUNCTION (Garage

inhibition)

The function "Garage inhibition" allows the temporarly deactivation of the automatic arming

and it is useful for leaving the vehicle in attended parkings where you need to leave the

vehicle's key.

With this function activated you can leave the keys, keeping the remote control and the

emergency key with you. This is suggested to avoid the unauthorized use of the control

set.

Turn the ignition key ON and, within 20 seconds, proceed in the following way:

1) Press button B on the radio control. The system will indicate that it has received the

command by sounding the buzzer twice and the LED start to flash.

2) Switch off the engine. The buzzer will indicate that the automatic arming function has

been inhibited by two sounds. Every time the ignition key is turned OFF this acoustic

signalling will be repeated until the automatic arming will be deactivated

While using the car you will see the LED blinking fast as long as the engine remains on.

The pr

The protection function will r

The pr

otection function will r

otection function will reset the first time the radio contr

otection function will r

eset the first time the radio contr

eset the first time the radio control is used or

eset the first time the radio contr

after the ignition has been turned on ten times.

after the ignition has been tur

ned on ten times.

ILLUMINATED ENTRY

If the system fitted offer this feature the courtesy light will be illuminated for 30 s

when the alarm is disarmed. The light will go off when the timer is elapsed or when the

ignition key is turned on.

ol is used or
