signalling that the PIN is correct and that the electronic key has been identified.
6. 6. 6. 6. 6. Keep pressed the remote control A button for 5 seconds. The LED will go OFF and
then it will inform you by a long blink that you are positioned in the mode table.
A group of faster blinks identify the selected mode: 1 blink means mode A, 2 blinks mean
mode B and so on. Press button A of the remote control to change from one mode to the
next as soon as the number of blinks corresponds to the selected mode.
Press button B of the remote control to confirm the selected mode; the group of blinks will
become slow to show that the choosen mode as been activated.
If you don't want to change the corrent setting or you don't remember the original setting,
don't press the remote control B button and proceed turning the ignition key OFF; in this
way you will mantain the courrent setting.
The way of blinking of the LED is the following:
MODE A
1 1
MODE B
2 2
MODE C
3
Turn the ignition key OFF and then ON to go to the next table. The LED will go OFF
and then it will inform you by two long blinks that you are positioned in the function
table. As explained for the mode table (remote control A button for the selection and B
button for confirmation) you can choose the more suitable setting for your application.
Turning the ignition key ON and OFF again you can program the buzzer volume the
LED will inform you by three long blinks that you can adjust the buzzer volume:
by pressing the remote control A button the volume increases while pressing B button
decreases. Every time you press a button the buzzer will sound to let you check the
new volume level.
50 GB
1 1
2
2
3 3

DATA TABLES

DATA TABLES DATA TABLES DATA TABLES DATA TABLES
MODE TABLE MODE TABLE MODE TABLE MODE TABLE MODE TABLE
CDL Closing Relay
operating time
Mode
(violet wire)
A = 1 blink 1 s
B = 2 blinks
1 s
C = 3 blinks
24 s
D = 4 blinks
controlled by TX
E = 5 blinks
1 s
F = 6 blinks
1 s
G = 7 blinks
24 s
H = 8 blinks
controlled by TX
CHIAVE OFF
FUNCTIONS TABLE FUNCTIONS TABLE
FUNCTIONS TABLE FUNCTIONS TABLE FUNCTIONS TABLE
KEY OFF
Passive Arming
Function Active Arming
(Immobiliser)
F1 = 1 blink ON
F2 = 2 blinks ON
F3 = 3 blinks ON
F4 = 4 blinks ON
F5 = 5 blinks ON
F6 = 6 blinks ON
F7 = 7 blinks OFF
F8 = 8 blinks OFF
F9 = 9 blinks OFF
F10 = 10 blinks OFF
F11 = 11 blinks OFF
F12 = 12 blinks OFF
CHIAVE OFF
KEY OFF
Buzzer Volume : 0 ÷ MAX
window closing
time
Voltage Drop sensor
(brown/white wire)
controlled by TX
ON
24 s ON
24 s ON
controlled by TX ON
controlled by TX OFF
24 s
OFF
24 s
OFF
controlled by TX OFF
Factory
Set-up
CHIAVE ON
KEY ON
white/red wire outlet selection
(siren/horn)
ON
continuous
ON
intermittent
ON output controlled by B button
OFF continuous
OFF
intermittent
OFF
output controlled by B button
ON
continuous
ON intermittent
ON output controlled by B button
OFF continuous
OFF
intermittent
OFF
output controlled by B button
Factory
Set-up
VOL = 0
CHIAVE ON
KEY ON
