Operation Panel

For the names of keys and indicators required when functions other than FAX are used, refer to the machine's Operation
Guide.
Displays the Status/Job
Cancel screen.
Displays the Favorites
screen.
When using an
application, displays the
application screen.
Displays the Document
Box screen.
Numeric keys.
Enter numbers and
symbols.
Displays the System Menu/Counter
screen.
Displays the Copy
screen.
Displays the screen for
sending. You can send
the FAX on the basic
send screen.
Displays the FAX screen.
Ready to send.
FAX
On Hook Chain Direct
Recall
Address Book Ext Address Book One Touch Key
Functions
Touch panel. Displays
buttons for configuring
machine settings.
Clears entered numbers and
characters.
Press to specify a registered
destination by a number, such
as a speed dial or address
number.
Finalizes numeric key entry,
and finalizes screen during
setting of functions. Operates
linked with the on-screen
[OK].
10:10
Dest. :
Check
Add Dest.
Favorites
Processing: Blinks during fax transmission and reception.
Memory: Blinks while the memory is being accessed.
Lights steadily when a document is in memory.
Attention: Lights or blinks when an error occurs and a job is
stopped.
1-4
Ends operation (logs out)
on the Administration
screen.
Puts the machine into Sleep
Mode. Recovers from Sleep
if in Sleep Mode.
Lit when the machine's
main power is on.
Returns settings to their
default states.
Cancels or pauses the
printing job in progress.
Starts fax transmission
and processing of
settings.
