Communications Serial Commands - Microscan EZ Match Imager User Manual

Communications Serial Commands

Host Port Connections
Auxiliary Port Connections
RS-422 Status
Host Port Protocol
Preamble
Postamble
Response Timeout
LRC
Auxiliary Port System Data Status <K146,aux port system data status>
ACK/NAK Options
Polling Mode Options
Autoconfiguration Daisy Chain
EZ Match User's Manual
<K100,baud rate,parity,stop bits,data bits>
<K101,aux port mode,baud rate,parity,stop bits,data
bits,daisy chain ID status,daisy chain ID>
<K102,status>
<K140,protocol,address>
<K141,status,preamble characters>
<K142,status,postamble characters>
<K143,response timeout>
<K145,status>
<K147,RES,REQ,STX,ETX,ACK,NAK>
<K148,RES,REQ,STX,ETX,ACK,NAK>
<K150DAISY>
Communications
4-3
