Matchcode by ESP

Matchcode by ESP

Click the Parameters
button and then the
Matchcode tab.
To change a setting,
double-click the
setting and use your
cursor to scroll
through the options.

Matchcode Serial Commands

Matchcode Type
Number of Master Symbols
New Master Pin
Enter Master Symbol Data
Request Master Symbol Data
Delete Master Symbol Data
Match Replace
Mismatch Replace
10-2
To open nested options,
single-click the +.
<K223,matchcode type,sequential matching,match start
position,match length,wild card character,sequence on
No Read,sequence on mismatch>
<K224,number of master symbols>
<K225,status>
<K231,master symbol number,master symbol data>
<K231?,>[for all] or <K231?,master symbol number>
<K231,master symbol number,>
<K735,status,match replacement string>
<K736,status,mismatch replacement string>
