4 - 4 LI2208 Product Reference Guide
RS-232 Host Parameters
Various RS-232 hosts are set up with their own parameter default settings
Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, Olivetti, Omron, or terminal sets the defaults listed
below.
Terminal Specific RS-232
Table 4-2
Parameter
Transmit Code ID Yes
Data Transmission Data/Suffix
Format
Suffix CR (1013)
Baud Rate 9600
Parity Even
Hardware RTS/CTS
Handshaking Option 3
Software None
Handshaking
Serial Response 9.9 Sec.
Time-out
Stop Bit Select One
ASCII Format 8-bit
Beep On <BEL> Disable
RTS Line State High
Prefix None
Notes:
In the Nixdorf Mode B, if CTS is low, scanning is disabled. When CTS is high, scanning is enabled.
If you scan Nixdorf Mode B without connecting the linear imager to the proper host, it may appear unable
to scan. If this happens, scan a different RS-232 host type within 5 seconds of cycling power to the linear
imager.
The CUTE host disables all parameter scanning, including Set Defaults. If you inadvertently select CUTE,
scan *Enable Parameter Bar Code Scanning (01h) on page 7-5, then change the host selection.
In ASCII format, when 7-bit is selected, Parity must be set to Odd or Even. If Parity is set to None, the
scanner automatically operates in 8-bit mode, even if 7-bit is scanned.
Wincor-
ICL Fujitsu Nixdorf
Mode A
Yes Yes
Data/Suffix Data/Suffix
CR (1013) CR (1013)
9600 9600
None Odd
None RTS/CTS
Option 3
None None
2 Sec. 9.9 Sec.
One One
8-bit 8-bit
Disable Disable
Low Low
None None
(Table
Wincor-
Nixdorf Mode Olivetti
B/OPOS/JPOS
Yes Yes
Data/Suffix Prefix/Data/
Suffix
CR (1013) ETX (1002)
9600 9600
Odd Even
RTS/CTS None
Option 3
None ACK/NAK
9.9 Sec. 9.9 Sec.
One One
8-bit 7-bit
Disable Disable
Low = No data to Low
send
None STX (1003)
4-2). Selecting the ICL,
Omron CUTE
Yes Yes
Data/Suffix Prefix/Data/
Suffix
CR (1013) CR (1013)
ETX (1003)
9600 9600
None Even
None None
None None
9.9 Sec. 9.9 Sec.
One One
8-bit 7-bit
Disable Disable
High High
None STX (1002)
