4 - 2 LI2208 Product Reference Guide

Connecting an RS-232 Interface

This connection is made directly from the scanner to the host computer.
RS-232 Direct Connection
Figure 4-1
To connect the RS-232 interface:
Attach the modular connector of the RS-232 interface cable to the host port on the bottom of the scanner.
1.
Connect the other end of the RS-232 interface cable to the serial port on the host.
2.
Connect the power supply to the serial connector end of the RS-232 interface cable. Plug the power supply
3.
into an appropriate outlet.
Select the RS-232 host type by scanning the appropriate bar code from
4.
The interface cable automatically detects the host interface type and uses the
NOTE
the default (*) does not meet your requirements, scan another host bar code.
To modify any other parameter options, scan the appropriate bar codes in this chapter.
5.
RS-232 Host Types on page
default setting. If
4-6.
