USER'S
GUIDE
HJT Model 100 Projector
Hughes-JVC Technology Corporation
2310 Camino Vida Roble, Carlsbad, CA 92009-1504 USA
760-929-5300
760-929-5410
-
service@hjt.com
e
F
AX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hughes JVC CB100

Summary of Contents for Hughes JVC CB100

  • Page 1 USER'S GUIDE HJT Model 100 Projector Hughes-JVC Technology Corporation 2310 Camino Vida Roble, Carlsbad, CA 92009-1504 USA 760-929-5300 760-929-5410 service@hjt.com...

  • Page 2: Declaration Of Conformity

    © Copyright 1997 by Hughes-JVC Technology Corporation. All worldwide rights reserved. This manual was produced by Hughes-JVC Technology Corporation and may be revised without prior notice. No part of this manual may be reproduced in any form without the express written permission of Hughes-JVC Technology Corporation.

  • Page 3: Table Of Contents

    0.5. Electrical Safeguards...ix 0.5.1. Power Supply...ix Chapter 1. Introduction 1.1. Shipping and Inspection...1-1 1.2. Items Shipped with the HJT Model 100 Projector ...1-1 1.3. Options ...1-2 1.4. Projector Control...1-2 1.5. Right and Left Orientation...1-2 1.6 Acronyms Used in Manual ...1-3 Chapter 2.
  • Page 4 4.7.3. Threshold Offset ...4-30 4.8. Uniformity (Shading) ...4-31 4.8.1. Sensitivity Uniformity...4-31 4.8.2. Threshold Uniformity...4-32 4.8.3. Color Balance (Grey Scale)...4-33 4.9. Picture Settings ...4-34 4.9.1. Brightness...4-35 4.9.2. Contrast ...4-35 4.9.3. Color, Tint, Sharpness ...4-36 4.9.4. Black Enhance ...4-36 4.9.5. VIC Settings...4-36 Hughes-JVC Technology Corporation...
  • Page 5 4.11.3. VIC Editing ...4-40 4.11.4. VIC Settings ...4-42 4.12. Updating Software ...4-44 Chapter 5. Preventive Maintenance 5.1. Preventive Maintenance...5-1 5.1.1. Cleaning the Cabinet...5-1 5.1.2. Cleaning the Projector Lens...5-2 5.1.3. Air Filters...5-2 Chapter 6. System Specifications Image Quality ...6-1 Input Compatibility ...6-1 Inputs...6-1 Control Ports...6-1...
  • Page 6 Table of Contents Hughes-JVC Technology Corporation...

  • Page 7: Safety Information

    HJT Model 100 Projector Service Manual. This HJT Model 100 Projector complies with the limits for a Class A computing device in accordance with the specifications in subpart J of Part 15 of the FCC Rules and Regulations.

  • Page 8: Heat Safeguards

    (refer to physical access and thermal clearance illustration guidelines). If a foreign object falls inside the projector, immediately unplug the projector and call a Hughes-JVC certified technician for object removal. CAUTION!!! arc lamp fan has stopped running. This fan protects the arc lamp from overheating.

  • Page 9: Electrical Safeguards

    0.5. Electrical Safeguards 0.5.1. Power Supply The projector operates from a 90-132VAC, 200-264VAC, 20/10 Amp, single-phase, 50-60 Hz AC power source. VERIFY THAT LOCAL POWER SOURCE MATCHES THESE REQUIREMENTS BEFORE OPERATION! Installation should be performed by an electrician with knowledge of current electrical codes in the country of use.
  • Page 10 Safety Information Hughes-JVC Technology Company...
  • Page 11 3.0...Operation 3.1..Executive Remote 3.2..Technician Remote 3.3..Power ON and OFF CAUTION!!! Before applying power to the projector thoroughly read the safety guidelines outlined at the beginning of this operator’s manual...3-6 3.4..Displaying Internal T 3.5..Displaying External S 3.5.1...Internal Source...

  • Page 12: Setup Preparation

    4.6..Convergence (XY Re 4.6.1...Purpose of Converge 4.6.2...Cursor Shapes and S 4.6.3...Convergence Profile 4.7..Black Level (G2) and 4.7.1...Black Level (G2) 4.7.2...Sensitivity Offset 4.7.3...Threshold Offset 4.8..Uniformity (Shading) 4.8.1...Sensitivity Uniformity 4.8.2...Threshold Uniformity Hughes-JVC Technology Company 4-10 4-10 4-18 ® Sensitivity and...

  • Page 13: Shipping And Inspection

    7.0...Glossary Of Ter 8.0...Indexes 1 The HJT Model 100 Projector accepts a variety of inputs and operates with a wide range of frame and raster rates. The projector meets these requirements with sophisticated computer terminal control, a unique optics system, a high-powered projection arc lamp...

  • Page 14: Options

    1 Infrared (IR) Remote Control—Can be used either as an IR remote or connected to the projector as a tethered remote. 1.3. Options The following options are available for HJT Model 100 Projector when ordered through Hughes-JVC: HJT Model 100 Projector Service Manual.

  • Page 15: Acronyms Used In Manual

    1.5. Right and Left Orientation References to the right and left side of the projector are with the operator standing behind the projector as the projector is directed at the screen (refer to Figure 1.0-1 on page 1-5). Figure 1.0-1 Top View; Left/Right Designation Table 1.0-1 Acronyms Used In Manual...
  • Page 16 Chapter 1—Introduction Hughes-JVC Technology Company...

  • Page 17: Installation

    2.8.2.1 Signal Inputs ...2-11 2.1. Air Flow and Maintenance Clearances The HJT Model 100 Projector should be placed in a location where it is easily accessible on both right and left sides. The area should be well ventilated, and the projector air intakes and exhausts should not be blocked in any way.

  • Page 18: Maintenance Access

    The illustrations in this section show the footprint and physical dimensions of the HJT Model 100 Projector. 686.4 692.1 Figure 2.0-1 Top View M100 Projector (dimensions in mm) 155.3 Figure 2.0-2 Bottom View M100 Projector (dimensions in mm) Metric 30.5 cm 61.0 cm...
  • Page 19 Chapter 2—Installation 911.3 897.2 14.1 35.1 Figure 2.0-3 Right Side View M100 Projector (dimensions in mm) HJT Model 100 User's Guide...

  • Page 20: Projector Orientation

    Figure 2.0-4 Front View M100 Projector (dimensions in mm) 2.3. Projector Orientation To accommodate various application requirements, the HJT Model 100 Projector can be placed in many different orientations with respect to the screen. Consider the following elements before installing the Model 100 to optimize the layout of the theater, meeting room, or projection booth.

  • Page 21: Projector-To-Screen Distance And Alignment

    2.4. Projector-to-Screen Distance and Alignment Set the projector to the proper distance from the screen as determined by the screen width and lens ratio illustration (refer to Figure 2.0-7 on page 2-7). The Lens Pattern illustrated in Figure 2.0-8 on page 2-8 will help determine the optimal screen widths and throw distances for the zoom lens.

  • Page 22: Lens Throw Distance And Screen Width

    For instance, if the projection lens being used is the 1.5:1 lens and the desired screen width is 3.65 meters (12 feet), the distance from the closest point of the screen to the projector lens is 5.48 meters (18 feet), as illustrated in Table 2.0-4. Table 2.0-4 Throw Distance Calculation Screen Width 3.65 meters...
  • Page 23 36 Feet Figure 2.0-7 Throw Distance vs Screen Width Illustration (3:1, 1:1 lenses) NOTE: Refer to the HJT Series 100 Projector Service Manual or the HJT Series 100 Projectors Projection Lens Installation Guide (shipped with the lens) when changing from the Zoom lens to a fixed lens or from a fixed lens to the Zoom lens.
  • Page 24 Chapter 2—Installation 1.5:1 Screen Width (meters) The Zoom lens can be used for any screen width and throw distance points that fall inside the shaded zoom lens outline. Zoom lens numbers represent the ratio of throw distance to screen width. A throw distance of 20 and a screen width of 4 is indicated by the in the shaded area of the chart.

  • Page 25: Power Requirements

    A qualified electrician must be utilized if custom power applications are necessary. Hughes-JVC will not be responsible for any hazards caused by unlicensed personnel changing the original single phase, 3-wire design power connection.

  • Page 26: Terminal Or Remote Control

    An optional Tethered Technician LCD Remote that includes the addition of a four (4) line display is also available. 2.7.2. Infrared (IR) Windows The projector has two (2) IR windows—one in front and one in back. These windows receive projector control signals from the IR remote. 2-10...

  • Page 27: Sources

    Key parameters are the horizontal and vertical scan rates, interlaced or non-interlaced scanning, and plus/minus sync levels. The projector can handle up to 20 sources in one channel. The correct projector source file is matched and automatically selected for the source being received by the projector.
  • Page 28 Comm Setup (see Section 3.6 on page 3-8 about Navigating the Menu in reference to video switchers). If using a communications controller such as an AMX or Crestron, connect it to either port A or port B. Use only one (1) controller per projector. 2-12 Hughes-JVC Technology Corporation...

  • Page 29: Executive Remote

    (see Figure 3-8) on the projector’s rear panel. One (1) end of the tether cable is terminated in a phone jack and the other end has a telephone jack. The IR function is disabled when the tether cable is plugged into the remote.
  • Page 30 Chapter 2—Installation Figure 3.0-1 Executive Remote Control Descriptions of key functions can be found in Table 3.0-1on page 3-5. Hughes-JVC Technology Corporation...

  • Page 31: Technician Remote

    3.2. Technician Remote The Technician Remote provides quicker access to some functions by using keys on the remote. In the Menu Structure Diagram (Figure 3.0-3 on page 3-11), these direct access functions are indicated by a symbol after the function name. Direct access features eliminate the need to access functions via the menu structure and save time during set up.
  • Page 32 Chapter 2—Installation Figure 3.0-2 Technician Remote Control Descriptions of key functions can be found in Table 3.0-1on page 3-5. Hughes-JVC Technology Corporation...
  • Page 33 Table 3.0-1 Remote Control Key Functions Press ON to turn power on, and OFF to turn power off. Power Menu Toggles on/off M Escape Cancels last command and retreats one menu level, cancels an input, exits adjustment Implements commands, chooses an item exits an Enter adjustment, goes to next menu level Cont...

  • Page 34: Power On And Off

    The orange LED should now glow green as the projector turns ON. A Hughes-JVC logo may appear on the screen for five (5) seconds. The screen then displays the external video or goes blank if no video signal is present.

  • Page 35: Displaying External Signals

    Select desired T 3.5. Displaying External Signals The internal test pattern on the screen shows that the projector is working properly. An external signal can now be displayed. The HJT Model 100 Projector has four (4) factory-preset channels. The operator can select one (1) of these preset channels to automatically display four (4) of the standard signals currently used.

  • Page 36: Internal Source

    33.3kHz (horizontal) and 59.3Hz (vertical) and is similar to HDTV. This internal source is used to display menus when there is no source input connected to the projector. To use this internal source, select C to any other channel but it cannot be cut, edited, or pasted to.

  • Page 37: Displaying The Main Menu

    Short menus allow very limited menu selections such as picture settings and channel selection. The short menu is useful for certain situations such as: The projector is already set up and operating; Frequent channel changes are occurring; Changes in picture settings are often necessary.

  • Page 38: Menu Selection Examples

    , (above second example) press the left arrow three IMING menu, press the right arrow three (3) times. During setup , Port A or Port B device, select V ETUP to be connected to Port A through the ANAGER Hughes-JVC Technology Corporation ATTERN IDEO WITCHER...

  • Page 39: Hjt Model 100 User's Guide

    Navigating the Menu: Press M on the Remote (or spacebar on a PC) to display the M . Press the number of the menu item needed (or use arrow keys to scroll to the item, then press E From the submenus, press the number of the selection wanted.

  • Page 40: Chapter 3-Operation

    Source File Data set in the projector’s memory created to handle a specific video source. Source files must be set up to match the specific geometric and convergence parameters in the incoming source.

  • Page 41: Active Channel

    NOTE: The Autoselect feature means that when the incoming source changes in the active channel, the projector automatically selects and switches to the source file within that channel that most closely matches the incoming source's parameters. The channel selected must have a source file set up to handle the type of incoming video or graphic source.

  • Page 42: Attaching A Source

    Selects the channel to receive that source; Names the channel to show the source type; Selects the VIC slot and/or VIC port to handle that source (if the projector uses an optional or a multi-port VIC); Follows the adjustment procedures in Chapter 4 on page 4-37 to set up a source file to handle that specific source.
  • Page 43 The attached sources are using the same source files (they are the same source files—not copies). A source can be attached to a source file from a different channel. Geometry and convergence settings must not be adjusted on attached sources because all attached sources will then be altered by the same adjustment.

  • Page 44: Picture Settings

    This column shows if the scan is interlaced or not ( I = interlaced, blank = non-interlaced). 60.2+ in Figure 3.0-5. The active OURCES list in the upper right corner of Figure 3.0- Hughes-JVC Technology Corporation list (CH 14). LACK...

  • Page 45: Menu Item Definitions

    3.11. Menu Item Definitions This section defines the menu items available through the M submenus. Table 3.0-7 Available Menu Items MAIN MENU Description Sub-Menu Description Displays picture adjustments and VIC settings. A small window contains the ICTURE adjustment name and the current data value. When the value is highlighted the user may enter a new value.
  • Page 46 SyncTip, or TriLevel. Default is back porch. centering. correction. correction. rotation. linearity correction. correction. should be un-checked only when doing Geometry procedures or for specific maintenance by service personnel. The default is O Hughes-JVC Technology Corporation ). This box EGISTRATION...
  • Page 47 MAIN MENU Description Sub-Menu Description Displays the following convergence parameters: ONVERGENCE XY adjustment for red, green and blue. EGISTRATION R, G, and B adjustment for varying the brightness of the dark HRESHOLD R, G, and B adjustment for varying the brightness of the bright ENSITIVITY R, G, and B adjustment for offsetting the brightness of the dark HRESHOLD...
  • Page 48 This backup data can be imported whenever a System Controller board is replaced. Used with #4 E MPORT above. ONFIGURATION Dialog to change timer value. ESET IMER Hughes-JVC Technology Corporation and 9600 Baud. ® light valve ® Sensitivity is changed. XPORT ONFIGURATION...

  • Page 49: Short Menu Structure

    MAIN MENU Description Sub-Menu Description HANGES ENUS OGGLE 3.12. Short Menu Structure Short menus allow very limited menu selections and prevent inadvertent changes in setup data when several operators are using the remote. To use short menus: Press M From the M 1.

  • Page 50: Pc Or Vt-100 Terminal Control

    Chapter 3—Operation 3.13. PC or VT-100 Terminal Control The projector can be controlled by a VT-100 terminal. If a VT-100 is not available, a PC with W INDOWS 10 on page 3-23 shows the equivalent commands for the terminal and both remotes.

  • Page 51: Communications Protocol

    3.13.2. Select S Set the following communications parameters and modes. Table 3.0-9 Communication Protocol Modes Baud Rate Data Bits Parity Parity Check Connector Stop Bits Flow Control Carrier Detect Select F from the menu bar and select N This will allow the user to select the file VT-100.TRM with the parameters listed in Table 3.0-9 saved for future use.
  • Page 52 Lens + Arrows Spacebar Menu Mode Onscrn +Shift+_ +Shift+^ key, the second number represents the L SCAPE Technician Remote Decimal Keys Hide Menu Mode 48-57 Onscrn Phase Size Pattern Skew Thresh Sens XYReg RACKET pressed. RROW Hughes-JVC Technology Corporation 30-39...

  • Page 53: Setup Adjustments

    4.0 Setup Adjustments Contents 4.1. Setup Preparation...4-2 4.1.1. Projection Lens Focus (Rough)...4-4 4.1.2. Editing Channels, Sources, and VICs ...4-5 4.1.3. Factory-Preset Channels and Sources...4-7 4.1.4. Internal Source...4-8 4.2. Timing Settings and Adjustments ...4-8 4.2.1. Clamp Type...4-8 4.2.2. VTR Mode...4-8 4.2.3. Blanking ...4-9 4.2.4.

  • Page 54: Chapter 4-Setup Adjustments

    All instructions are given with reference to using the menu tree for setup functions. If using a PC or laptop computer to control the projector refer to Table 3.0-10 on page 3-23 for the equivalent key functions.
  • Page 55 Chapter 4—Setup Adjustments HJT Model 100 User's Guide...
  • Page 56 This provides backup for a previously set up channel and a good starting point for setting up other channels. Also ensure that the "copied to" channel uses the same type of VIC as the "copied from" channel. If the projector uses only one (1) VIC, this is not applicable.

  • Page 57: Projection Lens Focus (Rough)

    If the projector uses more than one (1) type of VIC, the type can be determined by accessing the S VIC slot will be displayed with the type of VIC in each slot. Complete the Timing section first, Geometry next, and Convergence last.

  • Page 58: Editing Channels, Sources, And Vics

    CAUTION!!! does not have an exact match in a source file, the projector will match the source to the source file that is closest to the new source parameters. If adjustments are attempted, the following statement appears on the screen: “Adjustments are inhibited on an approximate match.”...
  • Page 59 NOTE: The only item in the S OURCES source name. All other columns and items are sensed by the projector and added automatically when the source is received. the new source is listed in the highlighted Channel. CHANNELS CH 3 (SVGA2)

  • Page 60: Factory-Preset Channels And Sources

    Also shows the source in brackets if this highlighted 72.0 channel is also active (on screen). 72.4 If the highlighted channel 60.8 indicated here is not the active channel, 60.2 the source is blank 50.1 61.1 60.2+ Hughes-JVC Technology Corporation list (CH 14).

  • Page 61: Internal Source

    VIC is used, the clamp type should be “Tri-level.” 4.2.2. VTR Mode Set VTR mode to ON position if the projector’s input comes from a VTR source or is line-doubled DVD. This setting stabilizes the VTR sync input. Otherwise, set the VTR mode to OFF.

  • Page 62: Blanking

    NTER SCAPE from the T menu. HASE IMING or E to exit this adjustment. SCAPE NTER LANKING ADJUSTMENT Hughes-JVC Technology Corporation , from the T ATTERN menu. ICTURE SCAPE menu. IMING from the or E when finished. SCAPE...

  • Page 63: Geometric Adjustments

    4.3. Geometric Adjustments Geometric adjustments are performed for each type of source. Timing settings must be completed before geometry can be performed correctly. NOTE: Toggle the R menu. This ensures that any previous convergence corrections will not influence the Geometry adjustments 4.3.1.
  • Page 64 These procedures are all somewhat interactive. Some back and forth repeat adjustments may be necessary to get the best geometry. 4-12 SCREEN RASTER IMAGE G-Skew/Rotate G-Linearity Edge Linearity Keystone Pincushion R/B-Centering R/B-Linearity R/B-Skew/Rotate Hughes-JVC Technology Corporation TO THIS IMAGE SHOULD LOOK LIKE THIS BEFORE FINAL SIZE AND BLANKING SETTINGS.

  • Page 65: Bow

    Figure 4.0-4 Undistorted Standard Crosshatch Test Pattern 4.3.3. Bow NOTE: Skip this procedure if the vertical centerline is straight and the horizontal centerline is level (refer to Figure 4.0-5 Bow Distortion on page 4- 14). With bow distortion, the picture bends in the same direction on the edges and in the center of the test pattern.

  • Page 66: Skew/Rotate (G)

    Perform the Rotate procedure first to make the horizontal lines horizontal. If the pattern leans left or right (as illustrated in Figure 4.0-7 on page 4- 15) proceed with the Skew procedure to correct. 4-14 Figure 4.0-5 Bow Distortion Hughes-JVC Technology Corporation...
  • Page 67 Figure 4.0-6 Vertical Rotation Distortion Figure 4.0-7 Skew Distortion-Vertical Centerline Tilted To correct for Rotation: 1. Select the Standard Crosshatch test pattern. 2. Select S 3. Toggle the RGB 4. Use the H 5. Use the up/down arrow keys to correct for vertical rotation. 6.

  • Page 68: Linearity (G)

    Vertical Linearity Distortion. Use up/down arrow keys to correct. Figure 4.0-8 Linearity Distortion (horizontal and vertical) 4-16 from the G INEARITY EOMETRY MENU to select G only. and hide R and B. IDE KEY to perform additional linearity INEARITY ADJUSTMENT to exit. SCAPE NTER Hughes-JVC Technology Corporation...

  • Page 69: Edge Linearity

    4.3.6. Edge Linearity Edge linearity adjustment corrects for improper grid spacing at the left/right edges and top/bottom of the image for all colors (refer to Figure 4.0-9). Horizontal Edge Linearity Distortion. Use left/right arrow keys to correct. Vertical Edge Linearity Distortion. Use up/down arrow keys to correct. Figure 4.0-9 Edge Linearity Distortion (horizontal and vertical) To correct for Edge Linearity Distortion: 1.

  • Page 70: Keystone

    2. Use the left/right arrow keys to correct for horizontal keystone distortion. Use the up/down arrow keys to correct for vertical keystone distortion. 3. Press E 4-18 from the G EYSTONE EOMETRY MENU to exit. SCAPE NTER Hughes-JVC Technology Corporation...

  • Page 71: Pincushion

    4.3.8. Pincushion The Pincushion adjustment corrects for warped distortion at the sides or top and bottom of the image. Use left/right keys for distortion at top and up/down keys for distortion at bottom. Figure 4.0-11 Pincushion Distortion (four views) To correct for Pincushion Distortion: 1.

  • Page 72: Centering (Red And Blue)

    B. Be sure that R and G are both on the IDE KEY to select R. to select B. and unhide B. All three (3) colors should now be on IDE KEY to exit the adjustment. SCAPE NTER Hughes-JVC Technology Corporation...

  • Page 73: Projection Lens Focus (Fine)

    4.3.11. Adjust Red and Blue Skew/Rotate to match Green as follows: 1. Select S 2. Hide B. Verify that R and G are both on the screen with B hidden. 3. Toggle the RGB 4. Use the up/down arrow keys and adjust R Green as closely as possible.

  • Page 74: Ila ® Sensitivity And Bias

    ® bias settings adjust the electrical bias levels ® assembly to react. When properly set, this ® assembly at the threshold of operation. If set Hughes-JVC Technology Corporation box in the OCUS NABLE OCUS YNAMIC OCUS test pattern from above.
  • Page 75 To set the ILA Under the S box is checked. Use the H Toggle the RGB Access ILA Use the up/down arrow keys to select an ILA in the screen window. This is the default setting and should be acceptable for general viewing.

  • Page 76: Convergence (Xy Registration)

    The XY Convergence adjustments are used to converge or overlay the Red, Green and Blue CRT images over the entire screen area. The HJT Model 100 Projector handles many different sources and convergence is tied directly to a video source. One (1) channel can contain up to 20 different sources with different formats.

  • Page 77: Convergence Profiled

    4.6.3. Convergence Profiled Start with a full-size cursor when the entire screen needs adjusting. To converge (XY Registration): 1. Start with the center of the cursor at the upper left corner. Note that cursor is off the screen at the top and left (see Figure 4.0- 12 on page 4-26).
  • Page 78 Center at Upper Left (Point 1) ¼ Figure 4.0-13 Screen Cursor Center at Upper Left (Point 1) Hughes-JVC Technology Corporation Start with the full screen cursor center at Point 1 and make corrections. Then move center of cursor down to Point 2 and make corrections.
  • Page 79 Figure 4.0-14 Three (3) Cursor Modes HJT Model 100 User's Guide Chapter 4—Setup Adjustments Move Mode with the arrow pattern in OVE MODE the center. Use the up/down and right/left keys to move the cursor to the area of the screen that needs convergence.
  • Page 80 OVE CURSOR to return to the S ODE KEY to hide Red and Blue. . The convergence EGISTRATION to toggle to the to toggle to the NTER to toggle to the S IZE MODE IZE MODE Blue Green Hughes-JVC Technology Corporation...
  • Page 81 Red is not correctly converged in horizontal direction. Use right/left arrows. Blue not correctly converged in vertical direction. Use up/down arrows. Figure 4.0-16 Incorrectly Converged RGB Patterns (two examples) Toggle the M 10. Use the arrow keys to move the center of the cursor to the upper left position (see Figure 4.0-12 on page 4-26).

  • Page 82: Black Level (G2) And Sensitivity Offset

    B only. Ensure that only the color to be adjusted is and select R ONVERGENCE MENU (G2), from the C LACK EVEL Hughes-JVC Technology Corporation to return NTER to the M . Refer to OVE MODE and toggle the M...

  • Page 83: Sensitivity Offset

    Figure 4.0-17 Grey/Pluge Test Pattern 4.7.2. Sensitivity Offset To adjust the Sensitivity Offset for Blue: 1. Access S should still be the only color on the screen with the Grey/Pluge test pattern still selected). 2. A screen will appear with a Sensitivity window. The window shows that Red and Green are hidden (greyed out) and Blue is the active color to be adjusted (repeat Steps 1 and 2 from Section 4.7.1 if Blue is not active).

  • Page 84: Uniformity (Shading)

    B only. from the T ARIABLE and select S CONVERGENCE MENU to the M ODE KEY to display the A NTER DJUSTMENT Hughes-JVC Technology Corporation YSTEMS REFERENCES MENU ATTERN MENU . The ENSITIVITY . Move the cursor to an URSOR URSOR...

  • Page 85: Threshold Uniformity

    13. Select a 4 X4 cursor and repeat Steps 9 - 11 again for this cursor, reducing the cursor size to adjust smaller areas, if necessary. 14. Press E 4.8.2. Threshold Uniformity Threshold sets the brightness at low (black) video levels to achieve a flat, uniform brightness in the black areas.

  • Page 86: Color Balance (Grey Scale)

    Offset adjustment. 4-34 from the T CALE ATTERN MENU and verify all colors are selected and on screen. and select the color that is too prominent in the from the C ENSITIVITY FFSET Hughes-JVC Technology Corporation ONVERGENCE MENU...

  • Page 87: Picture Settings

    Recheck the Sensitivity adjustment to locate this specific area, if possible, and increase or decrease its level accordingly. If this is not possible, the Shading procedure may have to be repeated. 4. If necessary, recheck and readjust threshold color balance. To adjust the Threshold Offset for the best color balance: 1.

  • Page 88: Brightness

    Access Test Pattern 1 (O Cont/Bright overlay pattern. 4-36 from the P RIGHTNESS ICTURE MENU to leave the B SCAPE RIGHTNESS from the P ONTRAST ICTURE MENU Hughes-JVC Technology Corporation ATTERN MENU RIGHTNESS adjustment. ONTRAST ) to remove the...

  • Page 89: Color, Tint, Sharpness

    VIC option settings when setting up new channel. 2. Press escape if the projector uses only one VIC. If the projector has more than one VIC option, refer to Section 4.11 on page 4-39 for details on how to set up for optional VICs.

  • Page 90: Backing Up Settings

    ASTE CAUTION!!! Verify that the channel copied to is blank. , then select the unwanted sources with the OURCE NTER Hughes-JVC Technology Corporation , which shows the VIC , select P ASTE to detach them from the ® Setting are...

  • Page 91: Video Input Cards

    Doubler) Illustrations of VIC input panels and connections are shown in Figures 4-18 (view of right side of projector) and 4-19 to 4-22 (VIC connections and indicators) at the end of this section. Prior to using a VIC, the following steps must be completed: Install the VIC into the slot to the right of the standard RGBHV inputs on the right side (facing the rear) projector.

  • Page 92: Installing (Or Removing) A Vic

    4.11.1. To install a VIC: 1. Turn projector power off with the remote. 2. Remove the two (2) screws and panel covering the optional VIC slot (see Figure 4.0-19). Slide the VIC into the VIC slot to the right of the standard RGBHV inputs.

  • Page 93: Connecting Vic Source Cables

    VIC column (see editing VICs, below) and using separate channels for their sources. 4.11.3. The VIC column in the C sources coming into the projector follow the correct path through the correct VIC input. To edit a VIC: 1. Select C 2.
  • Page 94 NOTE: When activating a Quad Standard Decoder Module VIC, be sure to have a proper source connected to the inputs on the rear panel. The projector will not select an appropriate source without a proper input source. 8. The channel and an appropriate source should now be named and edited in the C 4-2 about Setup Preparation.

  • Page 95: Vic Settings

    4.11.4. VIC Settings is necessary only when using a Quad Standard Decoder Module (with Line Doubler) VIC. After editing the VIC, the source video mode or format must be selected by using VIC S ICTURE MENU To select the source video mode or format: 1.
  • Page 96 Figure 4.0-20 Wide Bandwidth or Graphics Enhancer RGBHV VIC NOTE: Graphics Enhancer and Wide Bandwidth RGBHV VIC’s have the same inputs. Figure 4.0-21 Quad RGBHV Video Mux (multi-port) VIC Figure 4.0-22 Component HDTV (YP ) Input Module VIC 4-44 Hughes-JVC Technology Corporation...

  • Page 97: Updating Software

    NOTE: Refer to the any System Software release bulletin for Boot Manager version dependencies. To perform Software Upgrade: Use a Null Modem cable to connect a PC to the projector’s Serial Port A. Start W INDOWS Click on the Terminal Icon from the A From the T on DEC-VT-100(ANSI).
  • Page 98 (where x.x.0 is the currently loaded Boot Manager version [e.g. 1.3.0]). 4-46 Terminal Preferences Sound Block and Blink Fixedsys 15 none PC port being used 9600 or 19200 none XON/SOFF Pos 4 OFF = 19200 +_ to reboot the B HIFT Hughes-JVC Technology Corporation ANAGER screen INDOWS ERMINAL...
  • Page 99 * * * WARNING: IMPROPER USE MAY MAKE THIS SYSTEM UNBOOTABLE * * * (This warning relates to the Flash Memory updating in Step 11.4. Do not turn projector power off while the Flash Memory is updating.) Memory buffer reset to 0 Begin your S-record upload now (E...
  • Page 100 * * * WARNING: IMPROPER USE MAY MAKE THIS SYSTEM UNBOOTABLE * * * (This warning relates to the Flash Memory updating in Step 12.4. Do not turn projector power off while the Flash Memory is updating.) Memory buffer reset to 0 Begin your S-record upload now (E...
  • Page 101 System software update successful Command: __ When the Boot software has been successfully updated, re-start the projector by entering the projector will now restart with the updated System Software. HJT Model 100 User's Guide to continue, E to abort NTER...

  • Page 103: Preventive Maintenance

    Allow a discharge time of at least one minute for the high voltage to bleed off before removing the power plug. Do not turn off the circuit breaker at the rear of the projector until the arc lamp cooling fans have automatically stopped running.

  • Page 104: Cleaning The Projector Lens

    5.1.3. Air Filters Periodically inspect the air filters at the bottom and rear of the HJT Model 100 Projector for heavy accumulation of dirt and debris that may inhibit proper air circulation. The air filters can be cleaned with air guns, or submerged into a mild soap bath, being careful to thoroughly dry the filter before use.

  • Page 105: Chapter 6. System Specifications

    6.0 System Specifications NOTE: HJT Model 100 Projector specifications are subject to change without notice. Image Quality Brightness Contrast Ratio RGB Bandwidth Aspect Ratio Uniformity Graphics Resolution Video Resolution Video Response Time Color Coordinates Input Compatibility Horizontal Scan Frequency Vertical Scan Frequency...

  • Page 106: Operating Parameters

    Intake at rear; exhaust at right (rear view). Motorized Zoom 3.1 - 8.1 lens. Fixed 1:1 Wide Angle lens—Used for short projection distances and rear projection applications. Fixed 1.5:1 lens with offset—Needed for ceiling mounted applications or where wider projection angles are necessary. Hughes-JVC Technology Corporation...

  • Page 107: Chapter 6-System Specification

    Wide Bandwidth RGBHV Graphics Enhancer RGBHV Quad RGBHV Video Mux (multi-port) Component HDTV (YP ) Input Module Quad Standard Decoder Module (with Line Doubler) Extron System 8; Extron System 10; Extron Lancia; JVC switcher. HJT-Faroudja LD200/200U; VP250; VP400A/400A-U. Chapter 6—System Specification...
  • Page 108 Chapter 6—System Specifications Hughes-JVC Technology Corporation...

  • Page 109: Appendix A. Extron Switcher Interface To Model 100

    The baud rate for the Extron switchers is 19200. Since Port A is locked to a baud rate of 9600, Port B should be used for Extron Switchers. The projector port assignment must be selected and the VIC channel assignment must be edited for a switcher.
  • Page 110 19200 baud rate (Hughes-JVC emulation). This is usually done at Extron and a “Configured for Hughes-JVC” sticker is placed on the back of the unit. The Extron Service Manual for each unit describes how to reset the system to a state compatible with the HJT protocol, if necessary.
  • Page 111 If the channel change and power buttons work, but the video mute button does not work, turn power off on the remote (or PC), wait until the Arc Lamp fans have stopped running, then toggle the projector circuit to Off. This problem is an indication that the switcher did not receive the projector “Power On”...
  • Page 112 Appendix A—Extron Switcher Interface to Model 100 Appendix A-4 Hughes-JVC Technology Corporation...

  • Page 113: Appendix B-Configuration Data Export / Import Procedures (Rev 1.0.0)

    HJT Model 100 Projector Appendix B defines the steps to perform a Configuration Data Export and Import from the projector to a host computer. The host computer can be any system that has RS232 download and upload capability, including an IBM-PC compatible, an Apple MacIntosh, or a UNIX system—the following procedures are for an...
  • Page 114 4.c. above is performed. Data transfer will begin and continue until all source, channel, channel-source combination, and system data has been exported. The projector screen will display the following dialog during the transfer: XPORT XPORT IN -Press E...
  • Page 115 The W RANSFERS directory which contains several *.txt files— export file. Import will alter all projector setup data. Prior to starting, several warnings are displayed to prevent unintentional loss of setup data. HJT M ODEL...

  • Page 116: Appendix

    20 sources (500,000 bytes) at 9600 baud. f. At successful end, T HJT M ODEL When the projector detects the successful end of the transfer, the following screen is displayed: MPORT MPORT New Configuration is active...
  • Page 117 Press E to exit the projector import operation and return to the AINTENANCE If U BORT INDOWS ERMINAL First press S HJT M ODEL Then (second) press E Import Failed MPORT Old Data was Restored. Host S Press E Third (finally), press E and return to the M before the screen is redrawn.
  • Page 118 Appendix B—Export/Import Procedures Appendix B-6 Hughes-JVC Technology Corporation...

  • Page 119: Chapter 7. Glossary Of Terms

    U.S. television aspect ratio is four units wide to three units high (4:3). High Definition Television (HDTV) is 16:9. The ability of the HJT Model 100 Projector to automatically match the parameters (such as scan rates, sync types etc.) of an internal source file (for the active channel) to the parameters of an incoming video source.

  • Page 120: Chapter 7-Glossary

    Used to set Black level (G2) and Sensitivity Offset. High Definition Television. Has approximately twice the horizontal and vertical resolution of standard NTSC. HDTV systems are wide aspect ratio systems. Hughes-JVC Technology Corporation ® ®...
  • Page 121 It is the key component in producing very bright, high resolution images from Hughes-JVC large-screen projectors. Concentration of information or what would be seen if a black and white version of the image is displayed.
  • Page 122 CRT raster. If phase is misadjusted, the image may "wrap around" the edges or be positioned off the screen. Corrects for warped distortion at the sides or top and bottom of the image. The pincushion adjustment affects RGB. Hughes-JVC Technology Corporation...
  • Page 123 CRT-based video screen. One of many horizontal lines in a frame. The frequency of line scanning for a monitor or projector. "Sequential couleur a memoire" (sequential color with memory). The French color TV system also used within the Soviet Union.
  • Page 124 Input signal vertical scan frequency. Reverses the image vertically for use with ceiling displays or mirror-bounced displays. Information on these jumpers can be found in the HJT Model 100 Projector Service Manual. Hughes-JVC Technology Corporation ® settings setup data for...
  • Page 125 Vertical Synchronization Frequency Xenon Arc Lamp X-hatch HJT Model 100 User's Guide The number of times per second a frame is transmitted to a video display screen. See Arc Lamp. Test Pattern consisting of white horizontal and vertical grid lines. Used for a number of geometry adjustments. Chapter 7—Glossary Glossary-7...
  • Page 126 Chapter 7—Glossary Glossary-8 Hughes-JVC Technology Corporation...
  • Page 127 8.0 Indexes Index of Tables Table 1-1 Acronyms Used In Manual ...1-5 Table 2-1 Air Flow Clearances ...2-1 Table 2-2 Maintenance Clearances...2-2 Table 2-3 Lens Definitions...2-6 Table 2-4 Throw Distance Calculation...2-6 Table 2-5 Power Sources...2-9 Table 2-6 Standard Composite Signals ...2-11 Table 3-1 Remote Control Key Functions...3-5 Table 3-2 Internal Test Patterns...3-6 Table 3-3 On-Screen Factory-Preset Channel Menu Display ...3-7...

  • Page 128: Index Of Figures

    Figure 2-1 Top View M100 Projector (dimensions in mm) ...2-2 Figure 2-2 Bottom View M100 Projector (dimensions in mm) ...2-2 Figure 2-3 Right Side View M100 Projector (dimensions in mm) ...2-3 Figure 2-4 Front View M100 Projector (dimensions in mm) ...2-4 Figure 2-5 Maximum Projector-to-Screen Vertical Tilt Angle ...2-5...

This manual is also suitable for:

100

Table of Contents
