Hughes JVC G2000 Instructions Manual

D-ila digital graphics projector
Hide thumbs Also See for G2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
DIGITAL GRAPHICS PROJECTOR
MANUEL D'INSTRUCTIONS : PROJECTEUR GRAPHIQUE NUMÉRIQUE
G2000
For customer Use:
Enter below the Serial No. which is located
on the side panel of the cabinet. Retain this
information for future reference.
Pour l'utilisateur:
Inscrivez ci-dessous le No de série situé sur
le panneau latéral du coffret de l'appareil.
Conservez cette information à titre
d'information.
Model No.
G2000
No de modèle
Serial No.
No de série
G2000 Cover(A4)
3
INSTRUCTIONS
OPERATE
COMPUTER VIDEO
T
VOL.
ZOOM
FOCUS
W
MENU/ENTER
PAGE
BACK
PRESET
QUICK
AV
ALIGN.
MUTING
RM-M100 REMOTE CONTROL UNIT
99.11.19, 10:42 PM
