SYSTEM INSTALLATION

Installation of the camera must be performed by qualified service personnel in
accordance with all local and national electrical and mechanical codes.
Perform the following steps to install the camera.
1. Remove all components from the package and identify the items that will
be used during installation.
•
The camera with the CS lens mount
•
Mini din connector (for Video and DC type auto iris lenses)
•
C mount ring
•
Instruction manual
Other items used during the installation that are NOT supplied with the
camera may include:
•
12V DC power supply
•
Camera lens
•
Camera stand or mounting bracket
•
Video cable
•
Monitor
•
Mounting hardware
2. Select a suitable location for the camera. Install the camera stand or
mounting bracket in the selected location using a suitable fastener. The
camera stand or mounting bracket must be attached to a structural object,
such as a wall stud or ceiling rafter, that supports the weight of the
camera and mount. The minimum recommended load rating for the
bracket is 5 kg (11 lbs).
3. Attach the camera to the camera stand or mounting bracket using the
hardware supplied with the stand. The hardware connects to the 1/4" –
20 UNC threaded mounting hole on the top and bottom of the camera
housing.
Note: The mounting bracket on the camera housing can be attached to
the top or bottom of the housing to accommodate various installation
options.
4. Route the video cable from the monitor to the camera.
5. Plug the cable into the BNC output connector labeled "VIDEO OUT" on
the back of the camera.
