CAMERA OVERVIEW

( C MOUNT LENS )
( CS MOUNT LENS )
Level potentiometer
(for DC type A/I lens)
Function
Switch
Power Input
Terminal
1. Back Focus Ring
This ring is used to adjust the back focus length (distance between the
CCD and the back of the lens) by rotation of the ring in a clockwise or
counter-clockwise direction.
4
C Mount Ring
Back Focus Ring
BACK VIEW (12V DC)
LEVEL PWR
O N D C O N
LENS
OFF V I D OFF
E/I A/I AGC
VIDEO OUT
+ GND GND
12VDC
SIDE VIEW
Back Focus Lock Screw
Power LED
Auto Iris Lens
Connector
Video Out BNC
Connector
FRONT VIEW
Camera Mounting Bracket
