OVERVIEW

Automatically calls for help in an emergency
Thank you for choosing Skylink's Monitoring Station, MS200 to protect your family
and your assets. The MS-200 allows you to set up your own monitoring station
without any monthly fees! The MS-200 is ideal to be used in conjunction with any
existing security alarm systems that you can find on the market. Once your existing
security system's alarm goes off, Skylink's Audio Sensor AS-433 will be able to
detect the alarm from your system and therefore triggers the Automatic Dialer
AD-433S to call for help. You can program up to 9 different phone numbers, which
include your cellular phone, your office, your neighbor, your parents, or anyone else
you can think of. Once the callers receive the emergency message from the dialer,
they will be notified regarding the emergency situation.
Regardless of what kind of security system you are now using, as long as your
security system sounds an alarm when it is triggered, the MS-200 allows you to
eliminate all the monitoring fees that you've been paying for years and still main-
taining the service. If you did not have monitoring service before, you now can
enjoy such great service without paying any monitoring fees. You can also select
who to call during an emergency.
This manual is divided into 4 sections in order to assist you in the installation
and programming of your Monitoring Station.
1. Installation for the Emergency Dialer and Audio Sensor
2. Set up and Normal Operation of the Audio Sensor
3. Standard Programming of the Emergency Dialer
- Program the time clock
- Record a message
- Playback of pre-recorded message
- Storing telephone numbers in memory for
- emergency voice message only
- both emergency voice message and numeric pager information
- numeric pager information only
- Delete a telephone number from memory
- Modify a telephone number, the redial count and repeat times of a phone
number
4. Advanced Programming for the Emergency Dialer
- Programming the calling time
- Programming the pause period for pager access and telephone numbers
- Select the phone system (regular or PABX phone systems)
- Program transmitters / accessories to activate dialer
- Erase programmed transmitters / accessories
- To arm / disarm the dialer
- Universal Dial Tone
– –
5

INSTALLATION - DIAL ALERT

The Monitoring Station is installed using the screws provided. We have also
included double sided tape, to use for temporary installation while you are posi-
tioning the dialer. Once the devices are positioned correctly, install them permanently
with screws. We have also included wall anchors and a template to help position
the screws correctly.
How to use the template:
1. Cut the template in correct position.
2. Screw part way into the surface where the holes are marked.
3. Unscrew the screws and remove the template.
4. Screw the component in place where you started the screws.
INSTALLING THE DIAL-ALERT (AD-433S)
Position the dialer beside a telephone or near any phone line and within access
of an electrical outlet. However, it is recommended that you hide the dialer for
security purposes. The dialer runs on regular electrical current. It also contains
a 9 volt backup battery in case power is interrupted for any reason. A phone line
must be connected to the dialer in order for the dialer to work. Connect the phone
lines and AC adapter as shown.
Note: The optional line input is intended for answering machine, telephone
etc. The device connected to the dialer will be disconnected when the dialer is
activated. Therefore it will not affect the operation of the dialer.
There are 3 ways to attach the Dial-Alert on the wall:
1. Using double sided tape for temporary use.
2. Hanging it from the two keyholes on two stationary screws.
3. Screwing the back onto the wall with four screws.
To mount the Dial-Alert:
1. Open the case.
a) Press the two tabs on top of the
dialer.
b) Pull open the front.
–
12V DC
AC ADAPTER
OPTIONAL LINE INPUT FOR
PHONE ANSWERING MACHINE / TELEPHONE
TEL LINE IN
LINE
–
6
