STANDARD PROGRAMMING - DIAL ALERT
6. After pressing the [MEM] key, the display will show the current setting of the
repeat times.
7. If you want to keep the current repeat time, enter the [MEM] key. If you want to
change the setting, enter the desired number, (1 - 9), then press the [MEM] key.
8. The screen will revert back to clock mode.

ACTIVATE THE DIAL-ALERT WITH THE PANIC BUTTON ON THE KEYPAD

After you programmed all the emergency telephone numbers and the voice
message, you can activate the dialer by pressing the panic button on the keypad.
Once the panic button is pressed, the dialer will start dialing the pre-programmed
emergency phone numbers. You can also activate the dialer using the Panic
Transmitter. (PT-434, sold separately).
If the display shows "NO LINE" 1 minute after the panic button is pressed, please
check the phone line connection and the dial tone. If the connection is established,
and dial tone is normal, you may have to enable the "Universal Dial Tone" feature.
Please refer to page 21 for more detailed information.
– –
19
ADVANCED PROGRAMMING - DIAL ALERT

PROGRAM THE CALLING TIME

The calling time is the amount of time the phone will ring until the call is discon-
nected. If the phone is not picked up within this period of time, the dialer will either
call again, (depends on the redial count), or advance to the next phone
number. The calling time is currently set at 60 seconds.
How to program the calling time.
1. Press the [L] key, the display will show " L "
2. Press the [1] key, the diplay will show " L 1
setting of the call time, (in this example, it is currently 30 seconds, as per
chart below). To keep this setting, press the [L] key.
3. To change the calling time, press either 1, 2, 3, 4 or 5 when the diplay shows
" L 1 1 " (refer to the chart below)
1 =
2 =
3 =
4 =
5 =
If the display shows " L 1 3 ", the phone will ring for 60 seconds before the call
is disconnected.

PROGRAMMING A PAUSE PERIOD

When storing a phone number, you are able to insert a pause period between any
digits of the phone number or after the phone number and before the numeric
message (for pagers).
To set the pause period for pagers numeric message
1. Press the [L] key, the display will show " L "
2. Press the [2] key, the display will show " L 2
setting of the pause period (in this example, it is currently set at 5 seconds), to
keep this setting, press the [L] key.
3. To change the pause period, between 1 to 9 seconds, press (1 - 9) on the keypad
while the display shows " L 2 5 ". If the number 9 is entered, the pause period
between the number dialed and the numeric message is 9 seconds.
Program pause period between phone number and numeric message
Press the [R/P] key to insert a pause period between the telephone num ber and the
numeric information you want to send. The pause period is the time you have to wait
after the connection has been made to the paging company and before you can enter
the numeric information (i.e. phone number). The display will show a "P" if a pause
period is entered. This pause period is factory set at 5 seconds but can be changed
from 1 - 9 seconds. You may also insert m ultiple pause periods to suit your application.
Cal l t h e p a g i n g c o mpany t o d e t e r mi n e h o w l o n g t h e p a u s e p e r i o d s h o u l d b e .
–
1 ", the last digit, " 1 ", is the
30 seconds
45 seconds
60 seconds
75 seconds
90 seconds
5 ", the last digit, " 5 ", is the
–
20
