ADVANCED PROGRAMMING - DIAL ALERT
To insert a pause period in a telephone number
The length of the pause period [L*] can be programmed as shown.
1. Press the [L] key, the display will show "L".
2. Press the [ * ] key, the display will show "L* 3", the last digit, "3", is the setting
of the pause period, (in this example, it is currently set to 3 seconds, as per
chart below). To keep this setting, press the [L] key.
3. To change the pause period, press either 1, 2.....or 9 when the display shows
"L* 3".
1 = 1 second 2 = 2 seconds
4 = 4 seconds 5 = 5 seconds
7 = 7 seconds 8 = 8 seconds
When programming a telephone number to the dialer, (see STORING TELE-
PHONE NUMBERS), a pause period may be added between any digits of a phone
number. By using the " * " key on the keypad, a pause period will be entered. The
pause period will be anywhere between 1-9 seconds, (see the beginning of this
section to set the length of the pause period). Example, if you wanted a pause
between the third and forth number, the sequence would go as follows, 568*2095.
If the pause period was set at five seconds, there would be a five second delay
between the 8 and the 2.

SET THE TYPE OF PHONE SYSTEM

This dialer supports both regular telephone and PABX phone systems.
Selection can be made us ing the function key. The dialer is currently set for
regular phones.
To select the phone system:
1. Press the [L] key, display will show an "L".
2. Press the [3] key, display will show "L 3
dialer is set for regular phone.
3. To change the setting of the dialer to PABX systems, press [2].
The display will show " L 3 2 " and the system is now set to PABX system.

PROGRAM THE ID CODE OF A TRANSMITTER

Before any transmitter/sensor/security system console can activate the Dial-Alert,
they must be learned (programmed) to communicate with each other. As mentioned
in previous section, the Audio Sensor must be "learned" to the Dial-Alert in order
to connect these 2 devices wirelessly. The Dial-Alert can learn up to 16 different
devices, once these "learned" transmitters/sensors are activated, such as: the
button on the panic transmitter is pressed, a door with the door/window sensor
on it is opened, someone walks through an area monitored by the motion sensor
or the siren sounds on the security system, the dialer will begin to dial the preset
telephone numbers and play the pre-recorded message.
3 = 3 seconds
6 = 6 seconds
9 = 9 seconds
1 ", the last digit (1) means the
– –
21
ADVANCED PROGRAMMING - DIAL ALERT
To program Skylink's transmitters/sensors to the Dial-Alert (AD-433S):
1. Press the [L] key, display will show "L".
2. Press the [5] key, display will show " L 5
3. Activate the desired transmitter/sensor within 5 seconds after pressing the [5]
key. Refer to the user's instruction of the sensor to determine how to activate it.
Once the transmitter/sensor is learned to the dialer, the display will return to
clock mode.
4. To ensure that the sensor has been learned, activate the learned sensor when
the dialer is in the clock mode. If the dialer starts dialing the preset phone
numbers, the sensor has been learned. To terminate the dialing, press and
hold the Panic Button [O] on the keypad for 2 seconds.

DELETE PROGRAMMED TRANSMITTERS/SENSORS/SECURITY SYSTEMS

Once a transmitter/sensor/security system is learned, it is stored in memory. In
order to delete any one of the sensors, first the entire memory must be erased,
then re-learn the transmitters/sensors/security systems you wish to use. You
cannot erase only one specific sensor, the entire memory must be cleared.
To erase transmitters/sensors/security systems from the dialer:
1. Press the [L] key, the display will show " L ".
2. Press the [6] key, the display will show " L 6
3. Press the [#] key. If your hear a double beep, all transmitters/sensors/security
systems have been deleted.

TO ARM/DISARM THE DIALER

The dialer can be armed to send messages when the transmitters/sensors
that are learned have been activated. You can also disarm the dialer so that it
will not be activated even if any of the learned transmitters/sensors are activated.
You may choose to disarm the dialer when you are home and the door/window
contact on your front door is active. The dialer is currently set to arm mode.
To arm/disarm the dialer:
1. Press the [L] key, the display will show " L ".
2. Press the [7] key, the display will show " L 7
the dialer is armed.
3. To disarm the dialer, press the [2] key within 5 seconds after pressing the [7]
key . When the dialer is disabled, the display will read " L 7
When the dialer is disarmed, the disarm LED light will be on.
Id codE ".
ErASE ".
1 ". The last digit (1) indicates
2 ".
– –
