STANDARD PROGRAMMING - DIAL ALERT
6. The display will now show "rEPEAt 3". This is the repeat count which is the
number of times the message will be repeated during that one call. The
dialer is factory set to repeat the message 3 times. The number of repeats
can be changed from 1 to 9 times. If you want to keep the repeat count to
remain at 3 times, press the [MEM] key. To change the repeat count, enter
a number from 1 - 9 when display shows "rEPEAt 3" .
7. The dialer is now in standby mode. (Display shows the time).
The sequence to store a telephone number is as follows:
[MEM] , enter memory location (1-9) , enter telephone # , [MEM] , enter redial
# (1-9), enter repeat # (1-9).
B. Storing telephone numbers in memory (Sends both emergency
voice message and numeric information)
1. Press the [MEM] key, the display will show a letter "M" on the upper left corner.
If nothing is entered within 5 seconds, the display will return to the clock mode.
2. Within the first 5 seconds, select a memory location by pressing a keypad
number 1 - 9 to store the telephone number.
3. Enter the telephone number using the keypad. The display will flash as the
telephone is being entered. To insert a pause period between any digits of
the pre-programmed telephone number or after the telephone number and
before the numeric message (used for pagers), see PROGRAMMING A
PAUSE PERIOD (page 20).
4. Press [MEM].
5. "rEdIAL 3" will appear on the display. Th is is the redial count which is the number
of times the dialer will call that telephone number. The dialer is factory set to
call the number 3 times. The number of attempts can be changed to dial 1 to 9
times. If you want to keep the redial count at 3 attempts, press the [MEM] key. To
change the redial count, enter a number from 1 - 9 when d isplay shows "rEdIAL 3".
6. The display will now show "rEPEAt 3". This is the repeat count which is the
number of times the message will be repeated during that one call. The dialer
is factory set to repeat the message 3 times. The number of repeats can be
changed from 1 to 9 times. If you want to keep the repeat count to remain at 3
times, press the [MEM] key. To change the repeat count, enter a number from
1 - 9 when display shows "rEPEAt 3".
C. Storing telephone numbers in memory (Sends the numeric infor-
mation to pager only)
1. Press the [MEM] key, the display will show a letter "M" on the upper left corner.
If nothing is entered within 5 seconds, the display will return to the clock mode.
2. Within the first 5 seconds, select a memory location by pressing a keypad
number 1 - 9 to store the telephone number.
– –
17
STANDARD PROGRAMMING - DIAL ALERT
3. Enter the telephone number using the keypad. The display will flash as the
telephone is being entered. To insert a pause period between any digits of
the pre-programmed telephone number or after the telephone number and
before the numeric message (used for pagers), a pause period must be
added between the telephone number and the numerical message. Refer
to the Pager Company to identify the pause needed (see PROGRAMMING A
PAUSE PERIOD - page 20).
4. Enter the numeric information you want to send out, ( the information that will
be shown on the pager), then press [L]. This will suspend the recorded message.
5. Press [MEM].
6. After the telephone number has been stored, another message will appear on
the display asking for a redial count. The redial count is the number of times
the dialer will call that telephone number. The dialer is factory set to call the
number 3 times. The number of attempts can be changed to dial 1 to 9 times.
If you want to keep the redial count at 3 attempts, press the [MEM] key. To change
the redial count, enter a number from 1 - 9 when display shows "rEdIAL 3".
7. Input the repeat times when the display shows "rEPEAt 3". The repeat time is
the number of times the message will be played for that certain phone number.
The current setting is 3. It can be changed from 1 to 9 using the keypad. Again,
by pressing [MEM] will keep the existing setting.

DELETE A TELEPHONE NUMBER FROM MEMORY

1. Press [MEM] key.
2. Select the memory location (1 - 9) of the phone number you want to delete.
3. The phone number will be shown on the display, if that is the number you want
to delete, press the [R/P] key while the telephone number is on the display. Once
the phone number is deleted, the display will return to clock mode.
TO REVIEW OR MODIFY THE PRE-PROGRAMMED PHONE NUMBERS, THE
REDIAL COUNT AND/OR THE REPEAT TIMES OF A PHONE NUMBER.
1. Press the [MEM] key, display will show an "M" in the upper right corner.
2. Select the memory location of the phone number, (1 - 9)
3. The phone number will be shown on the display.
4. If you want to change the telephone number, enter the new phone number
while the old number is on the screen. This telephone number will be deleted
when a new number is added. Then press the [MEM] key. If you want to keep
the telephone number shown on the screen, press [MEM].
5. The display will now show the current setting of the redial count. If you want
to keep the current redial count, enter the [MEM] key. If you want to change the
setting, enter the desired number, (1 - 9), then press the [MEM] key.
– –
18
