Battery Maintenance; Dial-Alert - SkyLink Monitoring Station MS-200 Owner's Manual

– –
25
BATTERY MAINTENANCE - DIAL ALERT
The MS-200 comes with two 9V batteries that at some point you may have to
replace. One 9V battery for the Dial Alert AD-433S , and one 9V battery for the
Audio Sensor AS-433 .
Recommendation: Test your Dial-Alert and Audio Sensor periodically to ensure
that the batteries are working.
Dial-Alert Battery
The Dial-Alert comes equipped with a 9V backup battery in case the electrical
power is interrupted for any reason.
When the dialer backup battery is low, the "LOBATT" light goes on.
To replace the dialer backup battery:
1. Undo the two screws on the back of the

Dial-Alert.

2. Open the Dial-Alert case by pressing
down on the two tabs on the top edge
and pull the front forward.
3. Disconnect the old battery.
4. Connect the new battery.
5. Close the Dial-Alert case and re-insert the
two screws.
The battery life, (9 volt alkaline battery), is approximately two years if used only
for backup.
Note: If the AC adapter is disconnected while the battery is being replaced, the
pre-recorded message will be erased, and the clock will return to 12:00.
Re-record the emergency voice message and reset the clock. (Refer to page
15). The pre-programmed phone numbers will not be erased even when the
power is disconnected.
– –
26
