Configuration Settings Using the Web Interface

10
The following table contains the configuration parameters
recommended for interoperability with SpectraLink 8000 Wireless
Telephones.
Mode: AP
SVP: Enable
Voice SSID: Map to VLAN 100
QoS mapping: Map VLAN 100 to queue 3
Antenna Diversity: Enable
BelAir access radios implement SVP. BelAir backhaul radios can use
VLANs to assign voice priority to SpectraLink traffic or they can use
the 802.1p User Priority field to prioritize traffic.
The configuration shown above uses VLAN prioritization. Any
VLAN ID can be used. In the sample configuration given here, we
chose a VLAN ID of 100.

Connect to Web interface

Open a Web browser window and enter the BelAir node's IP address
in the navigation bar. Then log in with your BelAir administrative
credentials.
