1-1-2 Parts names
(1) Machine (front side)
11
3
1. Machine
2. Power switch
3. Cassette
4. Paper size label
5. Paper width guides
6. Paper length guide
9
5
4
Figure 1-1-1
8
7
2
6
5
7. USB memory slot
8. Top cover
9. Toner container
10. Lock lever (Toner container)
11. Developer unit
1-1-4
2LV/2L1/2L2/2MS/2MT
1
10
