(3) Printing an event log

Service items
Printing an Printing an event log (EVENT LOG)
event log
Description
Prints a history list of occurrences of paper jam, self-diagnostics, toner replacements,
etc.
Purpose
To allow machine malfunction analysis based on the frequency of paper misfeeds, self
diagnostic errors and replacements.
Method
1. Connect the USB or network cable between machine and PC (network).
2. Remove the inlet cover and connect the power cord.
3. Refit the inlet cover.
4. Turn the main power switch on. Make sure the machine is ready.
5. Send the following PRESCRIBE command sequence from the PC to the machine.
6. A sheet of event log will be printed.
Completion
!R!KCFG"ELOG";EXIT;
Description
Network cable
USB cable
Power cord
Figure 1-3-4
1-3-15
2LV/2L1/2L2/2MS/2MT
Inlet cover
