CAUTION
The selected grid code must match the actual installation site; otherwise the
inverter may not operate or be compliant to relevant local and national
regulations due to incorrect limit values.
NOTICE
• UK: Follow the local electrical regulations when selecting the grid code; either
normal grid code setting or UK 16A Limit restricted grid code setting with a 16A
limitation for G83 compliance.
•
Germany: Follow the local electrical regulations when selecting the grid code
setting; either Germany 126 (VDE 0126-1-1) or Germany 4105 (VDE-AR-N 4105).
The following screen is displayed while the settings are updated:
Grid Code Selection
NOTICE
An installation timer ensures that the grid settings can be changed (using the
Owner password) within 5 hours of feeding power to the grid. Thereafter it is only
accessible using the Installer password, which may only be obtained for installers
and grid operators by contacting Danfoss.
11. Reactive Power Setting
32
Enter – Call up the options
Select the actual reactive power setting:
1. For installations <= 13.8 kVA:
VDE 4105 0 – 13.8
2. For installations > 13.8 kVA:
VDE 4105 13.8 –
Enter – Confirm
Left – Back
Right – Next
Enter – Confirm
