LeMond Revolution 250202-2 Owner's Manual page 7

Before leaving the manufacturing facility, your LeMond
R
Your LeMond
EVOLUTION
damage. If damage is found please contact the delivery company and the LeMond Customer Service
Department at (612) 486-5750 to report any damage.
UNPACKING
Remove all components and parts from the packaging and check them against the list below and Figure 1.1.
The following items are included with your LeMond
Trainer Body Assembly with Shipping Base
Trainer Base Assembly
One (1) long button head M8 by 60mm screw
Skewer Assembly
Trainer Body Assembly
Trainer Base
should arrive packed in 1 carton. Upon arrival fully inspect the carton for
Assembly
ASSEMBLY INSTRUCTIONS
R
bike trainer was thoroughly inspected.
EVOLUTION
R
bike trainer:
EVOLUTION
5mm Allen key for assembly
Quick-Start Guide
Owner's Manual
1.85mm Spacer
Skewer Assembly
M8 x 60
1.85mm Spacer
5mm Hex Key
FIGURE 1.1
7
