MOUNTING YOUR BICYCLE TO THE LEMOND REVOLUTION
Note:
The LeMond Revolution is shipped from the factory equipped with a Shimano /SRAM 8/9/10/11-Speed
cassette adapter. If your bike is equipped with a Campagnolo
14 to change cassettes and cassette adapters. If you are unsure about the type of derailleur installed on your
bike please consult the documentation for your bicycle or visit your local bike specialist to ensure proper
compatibility with the Revolution.
1. Shift the chain on your bicycle to the smallest sprocket on the rear cassette.
2. Open the rear brake calipers on your bicycle and remove the rear wheel.
WARNING: CONSULT THE MANUFACTURER'S DOCUMENTATION FOR YOUR BICYCLE OR YOUR
!
LOCAL BIKE SPECIALIST IF YOU ARE UNSURE ABOUT THE CORRECT PROCEDURE FOR REMOV
ING THE REAR WHEEL OF YOUR BICYCLE.
3. Loosen the quick-release axle on the
axle. Be sure to position the spacer properly based on the type of bicycle you are using. (See Figure 3.1)
Note: If you are using a time trial
R
bike with the
EVOLUTION
you will need to remove the
skewer completely to install
your bike.
4. With the rear wheel removed guide the rear of your bicycle over top of the
that the chain rests on the smallest sprocket of the cassette on the
stays rest on the axle of the
R
and locate the axle spacer on the fan side of the
EVOLUTION
Road Bike / Triathlon Bike
R
. (Figure 3.2)
EVOLUTION

BICYCLE MOUNTING INSTRUCTIONS

®
derailleur, please follow the instructions on Pg.
Spacer Outside
Frame
Mountain / Cyclocross Bike
R
EVOLUTION
Spacer Inside
Frame
FIGURE 3.1
R
and ensure
EVOLUTION
and the bicycle chain
Chain on Smallest
Sprocket
Chainstays Resting
on Axle
FIGURE 3.2
11
